- Page 1 SkyboardPlus Electric Skateboard Quick Start Guide www.skywalkers.com.au...
- Page 2 Do Not Ride Without Reading Intended for use only by persons who are experienced skateboard riders. People with heart conditions, head, back or neck ailments, or pregnant women, should not operate the product. Children 14 and under should not operate the board. Keep away from all motor vehicle traffic safely when operating the board.
- Page 3 Do Not Ride Without Reading Never allow hands, feet, hair, body parts, clothing, or other items to come in contact with moving parts, wheels, or drive-train belt while the skateboard’s motor is running. Never use of headphones or a cell phone when riding. Never pluck a ride with vehicle. Do not ride your board in wet or icy weather and never immerse the board in water, as the electrical and drive components could be damaged and create other unsafe conditions.
- Page 4 USE WITH PROPER SAFETY PRECAUTIONS. WARNING USE AT YOUR OWN RISK. Read and understand the enclosed owner’s manual before riding. Use this product on dry paved ground without loose debris, such as rocks and gravel. The rider’s weight on this product should not exceed 2425 lbs (110kg) on short board/286.6 lbs (130kg) on long board. Do not allow children under age 14 to use this product.
-
Page 5: Ride Safely
Ride Safely ALWAYS WEAR A HELMET Read the warning labels at the beginning of this manual before riding. Only ride in an open dry flat area with smooth pavement. PROTECTIVE GEAR IS RECOMMENDED wrist guards elbow pads knee pads Every time you ride make sure you have appropriate safety gear on, athletic shoes, clothing that fits comfortable and not too loose. -
Page 6: How To Ride
How To Ride There are two stances wile riding a longboard: regular and goofy footed. Use which ever foot placement feels most comfortable to you. Goofy Motor Regular Motor Use the throttle on the controller slowly to prevent moving too fast. While riding, keep a low center of gravity and lean forward while accelerating, when braking, lean backward. - Page 7 Component Parts-Board Caution: This instruction book is written for universal use, all the pictures pls in kind prevail.
- Page 8 Glossary Goofy Motor Regular Motor Note: The lowest light on the remote tells the power level of both the board and remote control. If the light begins to flash quickly then the board battery is low and should be charged immediately. If the light begins to flash slowly (about 1 second interval) then the remote battery is low and should be charged immediately.
- Page 9 The Controller The board controller need to be fully charged before your first use. Before charging make sure both the board and the charger are powered off. The controller uses a standard micro USB to USB cable to charge. Plug the board controller micro USB cable into the bottom of the controller. Plug the USB end into the charger and into an outlet.
-
Page 10: First Ride
Charging The Board The board need to be fully charged before your first use. Before charging make sure both the board and the charger are powered off. Using any other charger may cause damage to the board or batteries, and will void your warranty. Plug the board charging cable into the board power port and plug the other end into a working outlet. -
Page 11: Fast Mode
Charging Speed Modes Power on the remote. Next immediately press the power button to swap between “fast” and “beginner” mode. Fast mode will light up the lower red led light. Beginner mode will light up the upper green led light. FAST MODE BEGINNER MODE Red Led... - Page 12 Board will not turn on. Charge the board and remote fully. Board and/or remote won’t charge. Make sure all plugs are securely in place. Check the board charge cables and ensure they are connected to each other. In very rare cases the battery may need replacement if it’s defective. Board turns on but will not run.
-
Page 13: Specifications
Specifications ShortBoard LongBoard Electric Net Weight 9.9 lbs (4.5kg) 12.6 lbs (5.7kg) Skateboard Product Size 26.9x8.8x5.4in (68.5x22.4x13.8cm) 37.3x9.9x5 in (94.8x25.3x12.8cm) Deck Material 7-ply maple 8-ply maple Capacity 4300 mAh (18650x14sections) 4300 mAh (18650x20sections) Type Lithium-Ion Lithium-Ion Battery Pack Charge Time About 3 hours About 3 hours Total Mileage...
