CoxOrb Cobalt User Guide
Congratulations on purchasing your new CoxOrb. It has been designed to be as easy as
possible to use but the following information will help you get the most from it. If you
do have any questions please email us at queries@active-tools.com or contact your
local distributor.
Start / Stop Button
Recall Button
Stroke Rate
Stop / Ready
Stroke Count
Decrease Volume Button
Audio / Charging Connector
Light Sensor for Backlight
Turn On
Turn Off
Volume Control
Mute
Basic Operation
Press & hold START/STOP for 3 seconds.
The unit will turn on in 'STOP' mode and Rate will be
displayed.
Press & hold START/STOP for 3 seconds.
Note that unit must not be in 'RECALL' mode.
Press INCREASE / DECREASE VOLUME buttons.
Volume level is displayed on the 'Volume Level
Indicator' and the level is saved when the unit is
turned off.
Press & hold MUTE button.
The unit will be muted and the 'Volume Level
Indicator' bars will disappear .
Volume Level Indicator
Split / Clear Button
Battery Level Indicator
Timer/Clock
Clock Button
Increase Volume Button
Microphone Connector
Mute Button
Advertisement
Table of Contents
Summary of Contents for Active Tools CoxOrb Cobalt
- Page 1 CoxOrb Cobalt User Guide Congratulations on purchasing your new CoxOrb. It has been designed to be as easy as possible to use but the following information will help you get the most from it. If you do have any questions please email us at queries@active-tools.com or contact your local distributor.
- Page 2 Press & hold CLOCK button. Clock The Time of Day Clock will be displayed. Recording a Work Piece Go To Ready Press START/STOP. Unit will go to ‘READY’ mode (all data fields ready to record). Start First boat movement or press START/STOP. When in ‘READY’...
- Page 3 Selecting Work Press INCREASE / DECREASE VOLUME buttons. Piece to View Work Pieces are labelled with the Time of Day they were recorded. The highlighted work piece will flash and if you leave it highlighted for more than 3 second it will be selected.
-
Page 4: Setting The Clock
Mounting Your CoxOrb CoxOrbs can be supplied with a mounting cup and will also fit existing mounting cups and moulded-in holders. The spherical back allows the unit to be angled to suit the user. Setting the Clock To set the Time and Date start with the CoxOrb turned on in ‘STOP’ mode and hold the ‘CLOCK’...
