EL208 Lanyard / Quick-Release Lock Pin Installation
1
3
Clip
Lock Washer
Bolt
4
2
Remove bolts and lock washers (identified in
the diagram), install the lanyard safety clips
(supplied) with the tab oriented towards the
inside of the cabinet (as shown). Fasten with
bolt and lock washer, tighten.
Install the safety clips similarly on the opposite
side of the Cabinet
5
6
Canada
U.S.A.
Voice: (905) 837-8481
Voice: (716) 297-2920
Fax: (905) 837-8746
Fax: (716) 297-3689
www.vtcproaudio.com
Manual-Owners-EL208T-QUICK-RELEASE-PIN-00-1v0-eng
550 Granite Court • Pickering, Ontario • L1W-3Y8 CANADA
4625 Witmer Industrial Estate • Niagara Falls, New York • 14305 USA
Printed in Canada
