Pro-Tech 8505 Owner's Manual

Battery powered commercial co monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Battery Powered Commercial CO Monitor
OWNER'S MANUAL

TABLE OF CONTENTS

1.... IMPORTANT MESSAGES AND WARNING
4.... CO MONITOR FEATURES & SPECIFICATIONS
12.... GOOD SAFETY HABITS / WHAT TO DO WHEN THE MONITOR SOUNDS
13.... DESCRIPTION OF AUDIBLE AND VISUAL SIGNALS
1. IMPORTANT MESSAGE AND WARNING
!
IMPORTANT!
AND SAVE THIS MANUAL FOR FUTURE REFERENCE.
!
CAUTION!
CARBON MONOXIDE GAS AT THE SENSOR. CARBON MONOXIDE GAS MAY BE
PRESENT IN OTHER AREAS. THIS CARBON MONOXIDE MONITOR IS DESIGNED
TO DETECT CARBON MONOXIDE GAS FROM ANY SOURCE OF COMBUSTION.
IT IS NOT DESIGNED TO DETECT SMOKE, FIRE OR ANY OTHER GAS.
WARNING!
!
RENDER THIS UNIT INOPERATIVE.
Do not try to repair this CO monitor yourself.
SECTION 14 for service.
READ ALL INSTRUCTIONS BEFORE INSTALLATION
THIS MONITOR WILL ONLY INDICATE THE PRESENCE OF
A DISCONNECTED OR LOW VOLTAGE BATTERY WILL
8505
Refer to the instructions in
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8505 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Tech 8505

  • Page 1: Table Of Contents

    8505 Battery Powered Commercial CO Monitor OWNER’S MANUAL TABLE OF CONTENTS 1…. IMPORTANT MESSAGES AND WARNING 2…. WHAT TO DO WHEN THE ALARM SOUNDS 3…. INFORMATION ABOUT CARBON MONOXIDE 4…. CO MONITOR FEATURES & SPECIFICATIONS 5…. RECOMMENDED LOCATIONS OF CO MONITORS 6….

  • Page 2: What To Do When The Alarm Sounds

    WARNING! ® The Pro-Tech 8505 Commercial CO Monitor is not designed for use in vehicles or unconditioned spaces, and is not listed to the residential UL 2034 standard. This monitor is intended for use within commercial buildings that are heated and air conditioned between 40°...

  • Page 3: Information About Carbon Monoxide

    3. INFORMATION ABOUT CARBON MONOXIDE WHAT IS CARBON MONOXIDE? Carbon monoxide (CO) is a highly toxic, invisible, odorless, tasteless gas. HOW IS CO GENERATED? Carbon monoxide is a byproduct of the incomplete combustion of fuel. Faulty ventilation of furnaces, space heaters, boilers, water heaters and kitchen appliances are a major cause of high CO levels in a building.
  • Page 4 4. CO MONITOR FEATURES • Battery Powered Commercial CO Monitor • Accurate and Reliable Electrochemical Sensor • Integrated Filter for Removing Nuisance Gases • Samples for Carbon Monoxide Every Second • Alpha Numeric LCD Readout with “Smart” Back Light • Continuous Display of Current CO Levels Detected from 9 to 999 PPM •...
  • Page 5 SPECIFICATIONS - Commercial Carbon Monoxide Monitor - Battery Powered: 9VDC - Sensor Type: electrochemical - Sample Frequency: every second - Display: continual LCD readout of actual CO levels detected from 9-999ppm - Display Resolution: 1ppm - Display Accuracy: +/-5% or 5ppm, whichever is greater* - Threshold Limit Value (TLV) alarm time: 20 ppm within 7 hrs TWA of detection - Recommended Exposure Limit (REL) alarm time: 30 ppm within 3 hrs TWA of detection - Permissible Exposure Limit (PEL) alarm time: 45 ppm within 90 minutes TWA of detection...

  • Page 6: Recommended Locations Of Co Monitors

    5. RECOMMENDED LOCATION OF CO MONITORS CO poisoning can happen anywhere in a building. At the minimum, CO monitors should be located on every level of the building, near the persons who may be potentially affected by CO poisoning, and where workers can hear any alarm. More than one CO monitor may be required within different areas of the building.

  • Page 7: Installation Instructions

    SECTION 6, LOCATIONS TO AVOID, PRIOR TO INSTALLING YOUR CO MONITOR. ® The proper power for the Pro-Tech 8505 commercial CO monitor is a 9V battery. Constant exposure to high or low temperatures or humidity may reduce battery life. BATTERY INSTALLATION AND REPLACEMENT: Slide down and remove battery door, and attach a new 9 Volt alkaline battery (Duracell MN1604 or Energizer MAX 522) to the battery cable.

  • Page 8: Operation

    ® In addition to the weekly test, the Pro-Tech 8505 CO monitor should be tested with a CO Detector Testing Aerosol at least once per year. Place an enclosure over the monitor, and follow the Aerosol’s instructions to perform the CO gas test correctly.
  • Page 9 the unit, and it will not alarm if exposed to CO. See SECTION 14 for service information. SENSOR LIFE MONITOR: The electrochemical sensor has a life expectancy of 2 years, however, the monitor’s CO readings will decrease in accuracy after the first year. A microcontroller counts the total time that the CO monitor is under power.

  • Page 10: Maintenance

    The monitor maintains the 30 most recent days of peak CO level history, and the most recent TWA value. To manually erase the record, press the button DISPLAY MEMORY once, and while the readings are being displayed, press button once. TEST/RESET/MUTE The monitor will sound one short beep and will appear on the LCD display.
  • Page 11 ability to hear the alarm. If you have a multi-level building, install CO monitors on each level. If the monitor is installed in a hallway and any office doors are kept closed, install a CO monitor in each room. If the monitor is installed in a large open area, one monitor should be installed for every 1000 square feet of vertically unobstructed space.
  • Page 12 13. AUDIBLE AND VISUAL SIGNALS Condition LCD Readout LEDs Horn Green LED blinks Displays “0ppm” continuously. Normal once every Silent Operation Backlight is OFF minute Beeps 4 times, pauses for 5 Red LED flashes Displays current CO reading in PPM. seconds.

  • Page 13: Service And Warranty

    Keep original sales receipt. Proof of purchase is required to obtain warranty service. ® Distributors, dealers or contractors selling Pro-Tech products do not have the right to alter, modify or in any way change the terms and conditions of this warranty.
