SeaLand VacuFlush 4700 Series Operation Manual

Vacuum toilet system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Vacuum toilet system
EN
Operation manual
Abwasser-Auslasspumpe
DE
Bedienungsanweisung . . . . . . . . . . . 12
Pompe d'évacuation
FR
Mode d'emploi . . . . . . . . . . . . . . . . . 12
Bomba de descarga
ES
Manual de instrucciones . . . . . . . . . . 12
Aftappomp
NL
Instructihandleiding . . . . . . . . . . . . . . 12
Pompa di scarico
IT
Manuale di istruzioni . . . . . . . . . . . . . 12
Tyhjennyspumppu
FI
Käyttöohje . . . . . . . . . . . . . . . . . . . . 12
Avloppspump
SV
Handbok . . . . . . . . . . . . . . . . . . . . . 12
Udledningspumpe
DA
Instruktionsmanual . . . . . . . . . . . . . . 12
Tømmepumpe
NO
Bruksanvisning . . . . . . . . . . . . . . . . . 12
4700 Series
VacuFlush
Toilets
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VacuFlush 4700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SeaLand VacuFlush 4700 Series

Summary of Contents for SeaLand VacuFlush 4700 Series

  • Page 1 Vacuum toilet system Operation manual Abwasser-Auslasspumpe Bedienungsanweisung . . . . . . . . . . . 12 Pompe d’évacuation Mode d’emploi . . . . . . . . . . . . . . . . . 12 Bomba de descarga Manual de instrucciones .
  • Page 2 Dometic 4700 Series VacuFlush Toilet...

  • Page 3: Table Of Contents

    Dometic 4700 Series VacuFlush Toilet Notes on using the manual Table of contents Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 General safety instructions .

  • Page 4: General Safety Instructions

    General safety instructions Dometic 4700 Series VacuFlush Toilet Caution! Hazard of Flooding If toilet is connected to ANY through-the-hull fittings, ALWAYS close seacocks when toilet is not in use (even if boat is unattended for a brief period) . All passengers MUST be instructed on how to close valves when the toilet is not in use .

  • Page 5: Components

    Dometic 4700 Series VacuFlush Toilet Intended use Benefits Convenient electronic flush. Add water or flush with the touch of a button or by operating the flush handle . No need to continue pressing button or handle for full flush to occur . Choice of two water consumption settings.

  • Page 6: Specifications

    Components Dometic 4700 Series VacuFlush Toilet Typical VacuFlush toilet system (marine) (fig . , page 2) Ref. Description Ref. Description 4700 series VacuFlush toilet Vent filter Flush switch/status panel Discharge pump Vacuum generator Overboard discharge fitting Holding tank status panel Air vent fitting Holding tank (waste) Dockside discharge fitting...

  • Page 7: Operation

    Dometic 4700 Series VacuFlush Toilet Specifications Dimensions (fig . , p . 2) All dimensions may vary ±3/8 inch (10 mm) Models with wall-mounted flush switch Models with flush handle Ref. Dimension Ref. Dimension 19 in . / 483 mm 19 in .

  • Page 8: Maintenance/Winterizing/Service

    Normal operation, push the button again . Maintenance / winterizing / service Cleaning the toilet To maintain the toilet’s original, lustrous appearance, use SeaLand Toilet Bowl Cleaner or other non-abrasive bathroom ® and toilet bowl cleaners . Please follow label directions .
  • Page 9 Dometic 4700 Series VacuFlush Toilet Maintenance/winterizing/service VacuFlush system maintenance Maintenance procedures vary widely and depend on factors such as frequency of use, quality of flushing water, etc . The chart provides a general guideline for keeping your toilet system ready for use at any time .
  • Page 10 Maintenance/winterizing/service Dometic 4700 Series VacuFlush Toilet 6 . Completely pump out holding tank . If system will be subjected to freezing temperatures, please follow above procedure, then winterize system as described in Section 7 .7 . TUrN OFF ElECTrICITY AND WATEr TO TOIlET IF IDlE FOr lONG PErIODS OF TIME If people will not be using the boat for a long time (vacation, maintenance, off-season, etc .), or in the event of a long electrical power interruption, electrical power and water supply to the toilet and vacuum generator should be shut off .
  • Page 11 Dometic 4700 Series VacuFlush Toilet Maintenance/winterizing/service Troubleshooting guide Toilet base assembly Electric flush handle Vacuum Breaker Bowl Seal Flush Ball Seal Electric Water Valve Retaining Ring Filter Screen Flush Ball Motor Drive Arm Linkage Rotor Shaft Cam Flush Spring Cam Switch Circuit Board Caution Use an ohmmeter and wiring diagrams of toilet and vacuum system when troubleshooting...
  • Page 12 Maintenance/winterizing/service Dometic 4700 Series VacuFlush Toilet Problem Possible Cause Service Instruction 2 . Water enters toilet bowl, but a . Green “OK to Flush” light is not a . Check for loose/defective wires toilet does not flush . lit on status panel . between vacuum switch (on vacuum generator) and wire 6 of toilet circuit board .
  • Page 13 Maintenance/winterizing/service Dometic 4700 Series VacuFlush Toilet Problem Possible Cause Service Instruction 9 . Flush ball does not open a . Rotor shaft cam is loose or a . See instructions for repair or completely . defective . replacement on pages 14-15 . b .
  • Page 14 Maintenance/winterizing/service Dometic 4700 Series VacuFlush Toilet Servicing toilet base components AlIGNING CAM SWITCH/FlUSH BAll The flush ball should be properly positioned so that the “A” and “B” distances are equal (see illustration at right) . If the flush ball becomes misaligned (resulting in water leaking from bowl or other flushing problems), follow instructions below to resolve problem .
  • Page 15 Dometic 4700 Series VacuFlush Toilet Maintenance/winterizing/service rEPlACING THE FlUSH BAll rEPlACING THE rOTOr SHAFT CAM 1 . Turn off water to toilet . 1 . Follow disassembly steps 1 through 14 under “Replacing the Flush Ball” . 2 . Open flush ball in Service Mode, then turn off power to toilet .

  • Page 16: Warranty

    Warranty Dometic 4700 Series VacuFlush Toilet Warranty and product liability North America and rest of the World: Manufacturer’s One-Year and Five-Year limited Warranty Dometic Corporation, Sanitation Division warrants to the original purchaser only that this product (certain Dometic products, listed below, have a longer warranty period), if used for personal, family or household pur- poses, is free from defects in material and workmanship for a period of one year from the date of purchase .
  • Page 17 Dometic 4700 Series VacuFlush Toilet Warranty Europe: Warranty and Customer Service Warranty arrangements are in accordance with EC Directive 44/1999/CE and the normal conditions applicable for the country concerned . For warranty or other service, please contact our Dometic Customer Service department . Any damage due to improper use is not covered by the warranty . The warranty does not cover any modifications to the product or the use of non-original Dometic parts;...

  • Page 18: Customer Service

    8:00 a .m . to 5:00 p .m . (ET) parts needs . They carry a complete inventory Monday through Friday . for the SeaLand product line . Telephone: 1 800-321-9886 U .S .A . and Canada...
  • Page 19 Dometic 4700 Series VacuFlush Toilet Notes...
  • Page 20 Dometic 4700 Series VacuFlush Toilet Dometic Group is a customer-driven, world-leading provider of leisure products for the RV, automotive, truck and marine markets . We supply the industry and aftermarket with a complete range of air conditioners, refrigerators, awnings, cookers, sanitation systems, lighting, mobile power equipment, comfort and safety solutions, windows, doors and other equipment that make life more comfortable away from home .
