Page 1 Multi Wheel Bluetooth Tire Pressure Monitoring System User Manual Model: External...
Page 3: Table Of Contents
Table of Contents 1. PRODUCT INTRODUCTION ................... 2 2. NOTICE ..........................2 3. BLE TPMS SPECIFICATION ................... 3 4. BLE TPMS PACKAGE ......................4 5. BLE TPMS SENSO R INSTALLATION ................4 6. APP DOWNLOAD AND INSTALLATION ..............7 7. SETTINGS & ADD DEVICE ....................8 8.
Page 4: Product Introduction
Tire condition is critical for the safety of riders and drivers, so getting a warning right from your vehicle that your tires have an issue could be a life saver. The BLU TPMS will monitor both the Pressure and Temperature of vehicle tires with external (D.I.Y.) IP Addressable O.E.M. Grade, Low Energy Bluetooth Sensors (BLE).
Page 5: Ble Tpms Specification
3. BLE TPMS Speciﬁcation BLU, BLE Sensor Speciﬁcation Operating Voltage Operating Humidity 95 % MAX ＜15 mA at DC 3V Operating Current -40℃ to 85 ℃ Storage Temperature -20℃ to 85 ℃ Operating Temperature Passenger: 0 to 92 psi (0 to 640 kPa)
Page 6: Ble Tpms Package
4. BLU TPMS Package Part List: BLE TPMS Sensor CR 1632 Battery Anti-theft lock Lock-Nut User Manual Wrench Voice Dongle (Optional) 5. BLU TPMS Sensor Installation 5.1 TPMS components and accessories 1.Battery(CR1632) 2.Tire Sensor 3.Anti-theft part 4.Lock-Nut 5. Wrench...
Page 7 5.2 Installation Steps (+ side up) Tire Sensor NOTE: We recommend metal valve stems for durability.
Page 8 Lock Nut Valve Stem After installation, please download the App to your smart phone, and proceed with all settings. (Please refer to section 7 “Initial Setting”)
Page 9: App Download And Installation
6. App Download and Installation 6.1 Operating System Requirements The BLU TPMS system supports both Android & iOS operating systems. (Bluetooth 4.0 required). App Download Operating System Compatible Smartphone iPhone 4S, 5, 5S, 6, 6S, Plus or iOS 7.1.2 or later...
Page 10: Settings & Add Device
7. Settings & Add Device 7.1 Intro screen Please make sure the “Bluetooth” & “Location Service” Settings are enabled when you start the App. iOS version Android version Login: Login Page (Pic 4a & 4b). Enter email and password if already set up.
Page 11 iOS version Android version To Register: Be sure the device is connected to the internet. Enter desired email account. Enter password. Password must be between 6 and 20 characters, capital, lower case and numbers. Once submitted, you will receive an email to your account with an activation link.
Page 12 iOS version Android version Main Menu: To add vehicle: Sign in and open left menu (Pic 7a/b), click on the upper left corner "+" button to add a vehicle, select the vehicle type .(2/3/4/6~36 wheel) (Pic 8a/b) Pic 7a Pic 7b Pic 8a Pic 8b...
Page 13 The following describes each method, you must use one of them to set up communication between the device and the sensors. Deﬂation set up: (not applicable for The external sensors, works only with internal sensors also available.) Pic 9b Pic 9a...
Page 14 iOS version Android version Pic 11a Pic 11b Manual set up: 1. Select Manual Learning. (Pic 12a/b) Pic 12a Pic 12b...
Page 15 iOS version Android version 2. Choose tire “1” and key in the ﬁve character sensor ID (Please refer to last page: ID sticker), which might include “0-9”, “A-F”, or ”a-f”, when a blank space pops up. (Pic 13a/b) The sensor ID is also etched on the top of each sensor.
Page 16 iOS version Android version QR Code set up: Select QR Code Settings. (Pic 15a/b) Pic 15a Pic 15b Choose tire 1 (LF) The APP will scan QR code, showing new ID number on the data ﬁeld. (Pic 16a/b) repeat for balance of sensors.
Page 17 iOS version Android version 3. The code will now show in the data ﬁeld. Repeat the process for the remaining wheels. 4. Press and hold the data ﬁeld to clear the ID’s if necessary. Pic 17a Pic 17b...
Page 18: Alarms And Warnings
8. Alarms and Warnings iOS version Android version System Warning ： Pressure, temperature and voice warning. (Pic 18a/b) When abnormal tire system status occurs, the value of the corresponding tire turns red, Shows a warning symbol and an alarm sounds. The warning symbols on each tire display are shown below.
Page 19: System Settings
9. System Settings iOS version Android version System Settings: (Pic 20a/b) Warning Audio Settings: Audio and mute . Voice reminder: Voice OFF/ON Vehicle settings: Vehicle edit.(9.1) Monitored pressure range settings: Select kPa、psi、Bar、 Kg/cm2 pressure units, ℃,℉, temperature unit and upper and lower limits.
Page 20 9.1 Vehicle Settings iOS version Android version System Settings: 1. Select Vehicle Settings, enter vehicle name、brand、 model. (Pic 21a/b). Pic 21a Pic 21b 2. Select Camera or Photos. then press the "Back “button to (Pic 22a/b) save the settings. Pic 22a Pic 22b...
Page 21 9.2 Monitored Pressure Range Settings iOS version Android version Monitored Pressure Range Setting: Select Monitored Pressure Range Settings (Pic 23a/b) , 1. Change settings on “front wheel” and “rear wheel” then press the “Back” button to save the settings. You can press “Reset to default” (Pic 24a/b) to reset all settings.
Page 22 iOS version Android version 2. Temperature Unit: ℃, ℉; Select temperature units (Pic 25a/b) then press the "Back “button to save the settings. 3. Pressure Unit: kPa, psi, Bar, Kg / cm2, select pressure units, (Pic 26ab) then press the "Back button to save the settings.
Page 23 9.3 Optional Voice Dongle Settings iOS version Android version Voice Dongle Set Up: NOTE: Recommended for 5V/2A car USB power adapter. NOTE: If kit is purchased with the dongle it will already be paired to the sensors. 1. To pair dongle to sensors, press the red voice dongle button for 1.5 seconds.
Page 24 iOS version Android version 3. The App will automatically download the settings when you hear “Setup completed”. (Pic 9a/b) When writing data, do not remove the voice dongle. Mute/ Un-Mute: Press the red button to mute. Press the red button again or wait 10 minutes for the mute function to cancel automatically.
Page 25 9.4 Exchange Settings iOS version Android version Drag the dialogue display of the tire to the desired location for all desired exchanged tires, then press the “Back” button to save the settings. It will display the new tire positions in sequence. Pic 30a Pic 30b 9.5 About...
Page 26: Frequently Asked Questions
If the tire has been damaged or trafﬁc accident resulting from improper driving behavior occurs, the company will not be responsible for any civil or criminal liabilities. Other relevant latest information of BLU TPMS is available at our website (www.techbyblu.com) and our Facebook Page (http://www.facebook.com/aacbrands) for latest information.
Page 27 Warranty Certiﬁcate Enter part number here:...
Page 28 www.techbyBLU.com...
