Summary of Contents for CATCO 1224
- Page 1 INSTALLATION, OPERATION, AND MAINTENANCE MANUAL CATCO CATALYTIC HEATERS PO Box 188 | Terrell, TX 75160 | 972.563.8065 www.catcoUSA.com | info@catcoUSA.com...
-
Page 2: Table Of Contents
Contents SAFETY ............................2 INSTALLATION & MOUNTING ....................2 FUEL GAS SET-UP .......................... 3 ELECTRICAL SET-UP ........................4 HAZARDOUS LOCATION INSTALLATIONS ................6 OPERATION ........................... 7 MAINTENANCE ..........................7 Explosionproof for Class I, Division 1 or 2 Group D, T2A -30 <... -
Page 3: Safety
SAFETY We value the safety of everyone using our products and Catco catalytic heaters have an outstanding track record of safety. They’re ideal heating solutions for many applications because they never require or produce a flame or spark during any phase of their operation. -
Page 4: Fuel Gas Set-Up
FUEL GAS SET-UP Catco catalytic heaters are best operated at a pressure of 4.5 inches water column (wc) for natural gas fueled heaters or 11 inches wc for LP gas fueled heaters. Operating pressures in Table 1 below indicate the flowing pressure measured at the heater orifice. -
Page 5: Electrical Set-Up
ELECTRICAL SET-UP When applicable, the heater must be electrically grounded in accordance with the National Electrical Code, ANSI/NFPA 70 or current Canadian Electrical Code, CSA C22.1. Before the catalytic reaction can begin, the catalyst bed must be preheated to approximately 250° F (121° C). This is accomplished by energizing internal electric heating elements using the voltage specified on the heater’s label. - Page 6 Table 2. Electrical connections for heating elements Parallel (12V or 120V) Series (24V, 240V, or 480V) Left/Right Configuration Models 1224, 1236, 1248, 1260, 1836 Top/Bottom Configuration Models 1848, 1860, 2424, 2448, 2460, 2472 Single Element Configuration Models 8RD, 12RD, 66, 88, 612, 1012,...
-
Page 7: Hazardous Location Installations
HAZARDOUS LOCATION INSTALLATIONS When installing a Catco heater in a Class I, Division 1 or Division 2, Group D area, ensure that all associated electrical equipment is appropriately rated for the area where it will be installed. Class I, Division 1 Installations In Class I, Division 1 installations the heater shall be supplied with an on/off switch connected by a suitable wiring method in accordance with Article 501.10 of the NEC. -
Page 8: Operation
MAINTENANCE Catco catalytic heaters contain no moving parts and maintenance is minimal. Sheet metal surfaces may be cleaned to prevent rust or corrosion, but take care to protect the face of the heater from contact with water, cleaners, or other foreign substances. If an area is being cleaned with high pressure water spray or air pressure, shield the face of the heater, as the catalyst can be damaged by water or rough contact.
