User Manual
The Raijuu loudspeakers are subwoofers operating from 20 Hz to 100 Hz. They are to
be coupled to limited-range loudspeakers via an active DSP crossover.
Please refer to Congard Code for the correct placement of your Raijuu Bass speaker to
achieve a realistic sound stage to compliment any film material in your cinema
http://audioexcellence.one/congardcode.html
Screen Excellence Ltd. 136 Bentwaters Parks, Rendlesham, Suffolk, IP12 2TW, UK Version 1.0
Advertisement
Table of Contents
Summary of Contents for Audio Excellence Raijuu 1
-
Page 1: User Manual
User Manual The Raijuu loudspeakers are subwoofers operating from 20 Hz to 100 Hz. They are to be coupled to limited-range loudspeakers via an active DSP crossover. Please refer to Congard Code for the correct placement of your Raijuu Bass speaker to achieve a realistic sound stage to compliment any film material in your cinema http://audioexcellence.one/congardcode.html Screen Excellence Ltd. - Page 2 Raijuu 1 The Raijuu 1 is a very small compact subwoofer designed to be shallow enough to fit in a drywall. It is a closed-box design operating below its resonance frequency, hence providing a band-pass response defined by a 2nd order low-pass function provided by a DSP unit.
- Page 3 Connections Close up detailing the signal binding post pair ready to receive the signal from the amplifier output channel. The binding post with the trace would be the positive black connection and the negative connection. Rubber feet are supplied to help isolate the speaker from any hard surfaces when it is located on the floor.
- Page 4 Raijuu 2 The Raijuu 2 is a compact subwoofer designed to provide the maximum impact and SPL for an ultimate playback of the LFE channel. It is a vented design. 1. Dimensions:650 x 550 x 339 mm 2. Weight:40 kg 3.
- Page 5 Connections Speakon 2 NL2MP signal input. The signal input can be found at lower right-hand side. Input Signal is connected to the driver via a NL2FX Speakon 2 plug, Same is used to connect the lead to the amplifier output channel. This Wiring connections to rear of the NL2FX signal plug: black...
