Janssens Victorian Vi-34 Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Version 2016_1.1
V
A
ICTORIAN
SSEMBLY
I
NSTRUCTIONS
Victorian Vi-23, 34, 36

Advertisement

loading
Need help?

Need help?

Do you have a question about the Victorian Vi-34 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Janssens Victorian Vi-34

Summary of Contents for Janssens Victorian Vi-34

  • Page 1 Version 2016_1.1 ICTORIAN SSEMBLY NSTRUCTIONS Victorian Vi-23, 34, 36...

  • Page 2: Product Information

    RODUCT NFORMATION Dear customer, Thank you for buying a high-quality aluminium greenhouse. EMARKS The drawings in these instructions are for all basic models. However, this manual should be sufficient to guide you through the assembly of all sizes and variations of this greenhouse.
  • Page 4 Side Profile Turning Door Side profile Turning Door Top Shelf Vertical Glazing Bar Top/Bottom profile of sliding door Hanger for Sliding Door Roof Glass Support pieces Rubber Gasket Bottom guide for sliding door Horizontal Profile Gable Profile Curtain Rail Turning Door...
  • Page 5 Royal Victorian Vi23 Vi23 2360 mm/ 92.91 in 3100 mm/ 122.04 in Vi34 Vi34 3100 mm/ 122.04 in 4580 mm/ 180.31 in Vi36 Vi36 3100 mm/ 122.04 in 6050 mm/ 238.19 in Note: Do not set concrete in the corners until the entire greenhouse frame is complete.
  • Page 6 This pages applies when you have a dropped door kit. Note: Divide millimeters by 25.4 to get inches...
  • Page 8 Note: When assembling the foundation in this step only hand-tighten the nuts. The corners may need to be slightly loose to attach the corner uprights Note: Before assembling the foundation insert 3 M6x15 bolts as shown for the sliding door guide.
  • Page 9 Insert a bolt into each upright on the Insert a bolt in corner side where the top of front and back wall shelf will be located. for Seed Tray. See page ZB2 and SC1...
  • Page 11 Suggestion: Now is a good time to install the L1 corner wind braces shown on page H10. Note: If you have purchased shade curtains, insert the slider loops into the gutter profile before this assembly step. This is shown below. 1-Twist lock per end 28 Slider loops per curtain...
  • Page 12 Note: A bolt needs to be added for the Note: Add three bolts to each Seed Tray support. See page ZB1. PRO1456 profile here for the Vi34: Add one bolt in the center louvre window. See page LR1 PRO1456 upright post Vi36/Vi46: Add one bolt in every other Note: Louvre window can PRO1456 upright post...
  • Page 13 Total amount of bolts to be inserted in roof beam center track at this point: 2 for L brackets - Pg H7 2 for roof supports - Pg H9 3 for misting system -Pg H14 Insert bolts to connect short uprights to the PRO6918.
  • Page 14 Note: Now is a good time to install the roof Note: Add one bolt braces. Refer to page H10. per end for the roof Note: If you have purchased curtains support tube. now is a good time to install the See page H9 curtain rails.
  • Page 15 Note: Roof window can be installed in any bay. Note: When installing the roof uprights, make note of which bays will have roof windows and insert a bolt for the connection plate.
  • Page 16 Note: Ends of support tube will need to be bent to fit. Attach the lower end and adjust the top until it fits flush.
  • Page 17 Drill a hole and attach wind brace to the roof profile with short screw or bolt Note: Wait until assembly is complete before attaching the roof braces to the roof uprights.
  • Page 18 Additional Roof Support for models over 16ft Note: On units longer than 16ft additional roof supports have been supplied. Install the supports as shown as close to the center as possible. Do not tighten the bolts. Lift the roof beam up 1/2 inch and then tighten all of the bolts for the supports.
  • Page 19 Note: Use a small slef- tapping screw to attach the plastic gutter down spout to the gutter profile and also the down pipe to the plastic downspout (Shown below) ------ Note: The gutter down pipe is attached to the base of the greenhouse with a screw that goes through the back of the elbow.
  • Page 20 Roof Glass Support Installation Note: Glass supports slide in from the end of the gutter profile to support the bottom of the glass. The supports should be spaced 100mm or 4 inches from each roof profile. H 14...
  • Page 21 Glazing Shim Installation Note: Glazing shims are now supplied to further strengthen the structure. Install the glass panels then fix the shims to either side of the glass with a dab of silicon. Then install the rubber trim. Polycarbonate units will not use these shims. Space the glazing shims 100mm or 4 inches from the top and bottom.
  • Page 22 Note: Crescent seal is only installed in the roof as shown. Not along side walls. Note: These trim plates are set in place with a dab of silicon and then the crescent seal is installed over them. Do not install crescent seal along side walls.
  • Page 23 This page is for polycarbonate units only. As shown below the blue transport tape is removed and replaced with a U-profile. The grey tape remains at the top to prevent contamination from dirt. The U-profiles are not used in the doors and windows.
  • Page 24 This pages applies when you have a dropped door kit.

  • Page 25: Sliding Door

    Sliding Door Note: If you have a double sliding door, install this screw 1 inch from end.
  • Page 26 Sliding Door Brush seal Glass Note: Rubber seal on installed on sides of door If you have two slidings doors the brush seal will only be installed on the outside edges.
  • Page 27 Double Sliding Door Note: Apply upwards pressure when installing the door support(in red). Note: Use washer underneath door hanger to level the door if needed. Add L bracket to close the gap between the doors when they meet.
  • Page 29 Louvre Vent ____ Note: Install washer between black louvre frame and the greenhouse upright at all four bolt locations. Note: If your model is equipped with the louvre vent automatic opener please refer to the Installation and Care manual packaged with the opener.
  • Page 30 Louvre Vent Note: Install washer between black louvre frame and the greenhouse upright at all four bolt locations. Squeeze black framing together to secure the glass...
  • Page 31 Roof Window 1 inch long bolt Note: A 1 inch long bolt is inserted into the lower profile. This bolt is for the optional manual opener or the spindle Glass opener. Note: Rubber seal is only installed on the sides of the roof window.
  • Page 32 Roof Window Installation Slide roof window into the roof beam from either end of the greenhouse. The hook part on the top of the roof window will slide into a groove in the roof beam. (shown below) Note: Inserting a bolt on either side of the roof window will prevent it from moving side to side . Manual Opener is shown above.
  • Page 33 Automatic Opener Installing the automatic opener requires 2 bolts to be inserted into the roof crossbar for the lower mount. The upper mount will clamp onto the lower roof window framing profile. (As shown in the diagram below) The automatic opener comes with its own instructions and care guide. These are located in the box with the opener. Insert 2 bolts for lower mount...
  • Page 34 Spindle Opener (If Equipped) Insert a 1 inch long bolt in the lower roof window profile. Slide it to the center and lock it in place with a nut as shown below. Next hold the lower U-shaped mount up to the crossbar and mark the center of one hole.
  • Page 35 Misting System Vi23 Vi34/36 (If Equipped) Note: If curtains are going to be installed, the misting system should be hung with bolts as shown to the left. The hangers will need top be bent into position. If there are no curtains it can be hung by drilling holes and hooking the hangers through them.
  • Page 36 Shade Curtain (If Equipped) Note: 4 round locking loops are provided. They are installed in the ends of the curtain rails. This prevents the curtain ends from The curtain rails can moving when you pull on them. be installed 2 ways. A.
  • Page 37 Seed Tray (If Equipped) 1 Support for every 10 foot section 1. Assemble three sides of the seed tray. Note: Make sure to slide 1 bolt into the bottom of the front and back seed tray profiles.(2 for a Vi34) 2.
  • Page 38 Seed Tray (If Equipped) 4. Use the bolts that you previously inserted into the uprights to mount the shelf end Note: If you have forgotten to insert the bolts support. Choose whatever height works you can use screws. Make sure to use a screw best for you.

  • Page 39: Top Shelf

    Top Shelf Suggestion: Use a small strip of tape under each bolt to hold it in place. This will make the shelf installtion a bit easier. (Tape shown as red dotted line.) The shelf can be installed at your desired height.
