Summary of Contents for Amprobe ATGC-1
- Page 1 ATGC-1 Ground Coil Users Manual...
- Page 2 ATGC-1 Ground Coil Users Manual ATGC1_Rev001 © 2008 Amprobe Test Tools. All rights reserved.
- Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 Ground Coil for use with Advanced Wire Tracers AT-2000 and AT-4000CON Series...
-
Page 5: Table Of Contents
ATGC-1 Ground Coil CoNTENTS Symbols .............................5 Unpacking and Inspection .......................5 Description ............................5 Setup and Inductively Coupled Signals ...................5 Tracing Underground Conductors, Water Pipes and Gas Pipes .............6 Setup ............................6 Finding the Conductor(s) ......................6 Positioning Coil for best signal Induction .................6... -
Page 6: Symbols
One person to hold the receiver and one person to adjust the coil position. Since the ATGC-1 creates a large field, it is possible that the field may be induced onto other known or unknown conductors in the area. By rewinding or recoiling the ATGC-1 so the overall diameter of the coil is smaller, the field will become smaller and may eliminate coupling to adjacent conductors in the area. -
Page 7: Tracing Underground Conductors, Water Pipes And Gas Pipes
30’ away from where you want to start identifying the location of the conductor. Arrange the ATGC-1 Ground Coil in a circle on the ground approximately 3’ from the top center of the conductor or pipe (Fig. 2). Note: placing the coil directly over the conductor will not induce any signal. -
Page 8: Technical Specifications
Remember to keep the receiver tip straight down, perpendicular to the ground with the front label and signal strength indictor facing the direction of the conductor run. To trace pipes or conductors over long distances, move the coil to the place where the signal dropped off and repeat the procedure. - Page 9 A ATGC-1 Ground Coil d B2024 Battery Pack b Conductor or Pipe E Transmitter C Receiver F Top Center of conductor or pipe Fig. 2 – Proper distance for initial setup. A ATGC-1 Ground Coil C Maximum Signal Strength b Conductor or Pipe d Little or no signal strength Fig.
- Page 10 A Maximum induction d Conductor Centerline b Less induction E Face Receiver towards coil C Calibration Point F Conductor Fig. 4 – Conductor centerline and Coil position adjustment...
- Page 12 • Catalog • Application notes • Product specifications • User manuals Please Recycle...
