Tegan Lighting OCULUS Installation Instructions Manual

OCULUS
LED Spotlight
1. CAUTION: Read all instructions.
• Do not install any Spotlight closer than six inches from any curtain or similar combustible material.
• Do not install this system in a damp or wet location.
• Turn off electrical power before modifying the lighting system in any way.
• Ensure the Spotlight connector is attached correctly to the system with no cross threading and is tightened down completely to make contact
with the top of the track.
• Ensure all connections are tight. Loose connections can cause overheating, arcing and a potential fire risk.
• Use only as described in these Tegan Lighting Installation Instructions.
• Use only Tegan Lighting supplied accessories.
• Luminaires may be extremely hot, allow to cool before touching.
• These are 24VDC Spotlights; they must be connected to an appropriate 24VDC power supply. Refer to Specification Sheets.
• For proper installation, have a qualified electrician install this product.
• This luminaire must be wired and grounded in accordance standard accepted electrical installation practices, local codes, and ordinances.
• Wire supply connections must be made with U.L. or comparible testing agency-approved connectors.
• Regular cleaning of these products is important. Switch off at main supply and allow to cool before touching. Clean fittings with a soft damp
cloth and allow to dry before reconnecting power supply.
Note: Refer to separate Gobo/Framing Projector Installation Instructions for additional details.
Short Glare Shield (SGS)
www.teganlighting.com
•
Gobo/Framing Projector (GFP)
info@teganlighting.com •
Installation Instructions
415-504-3536 TG-INS-09a
Tegan Trac
1
