Dor-O-Matic 95239-900 Installation Instructions Manual

Benchmark swing operator
Hide thumbs

Advertisement

Table of Contents

DOR-O-MATIC
AUTOMATIC DOOR SYSTEMS
Ò
Benchmark
Swing Operator
Installation Instructions
95239-900 Standard
95339-900 Premium
DOR-O-MATIC
AUTOMATIC DOOR SYSTEMS
7350 West Wilson Avenue
Harwood Heights, IL 60706-4708
1-800-543-4635
708-867-7400
Technical Support: 1-888-942-9945
Engineering Fax: 708-867-1177
www.doromatic.com
Ò

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 95239-900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dor-O-Matic 95239-900

  • Page 1 DOR-O-MATIC Ò AUTOMATIC DOOR SYSTEMS Benchmark Swing Operator Installation Instructions 95239-900 Standard 95339-900 Premium DOR-O-MATIC Ò AUTOMATIC DOOR SYSTEMS 7350 West Wilson Avenue Harwood Heights, IL 60706-4708 1-800-543-4635 708-867-7400 Technical Support: 1-888-942-9945 Engineering Fax: 708-867-1177 www.doromatic.com...
  • Page 2 WARNING CAUTION CAUTION...
  • Page 3 (screw pack not shown) (screw pack not shown) (screw pack not shown) (screw pack not shown) (screw pack not shown)
  • Page 5 NOTE...
  • Page 7 Right Hand Push System Shown...
  • Page 9 CAUTION CAUTION For clarity, not all components are shown on the control box PC board...
  • Page 10 Standard Control Box Wiring For clarity, not all components are shown on the control box PC board...
  • Page 11 Premium Control Box Wiring For clarity, not all components are shown on the control box PC board...
  • Page 12 WARNING...
  • Page 15 NOTE Feature Control Description Counterclockwise Clockwise...
  • Page 16 For clarity, not all components are shown on the control box PC board IMPORTANT...
  • Page 17 Dor-O-Matic ™ Benchmark Swing Operator Installation Instructions DOR - O – MATIC ® 7350 W. Wilson Ave. Harwood Heights, IL 60706 Toll Free: 1-800-543-4635 In Illinois: 708-867-7400 Sales FAX: 708-867-0291 www.doromatic.com 99101-084 Rev E February 2003 DA303...

  • Page 18: Installation Instructions

    Using the appropriate wiring diagram (Figure 25 for Standard or 26 for Premium) connect power and accessories as needed. Select proper function using SW2: (Premium Control Box only) Function 0: General Equipment – Any device not manufactured by Dor-O-Matic. Function 1: 77700-900 No Beam.
  • Page 19 Back Check Speed Adjustment: The back check speed is controlled by rotating P2 (CCW=SLOWER, CW= FASTER) on the Standard Control Box or P3 on the Premium Control Box (CW=SLOWER, CCW= FASTER). Hold Open Time Delay Adjustment: Adjustment is made by rotating P3 (CCW=LESS HOLD OPEN TIME, CW=MORE HOLD OPEN TIME) on the Standard Control Box or P1 (CW=LESS HOLD OPEN TIME, CCW=MORE HOLD OPEN TIME) on the Premium Control Box.

  • Page 20: Do's And Don'ts

    DO’S AND DON’TS Do use this operator on standard pedestrian doors, exterior and interior, weighing up to 200 pounds. For doors greater than 200 pounds, consult factory. Do Not connect any remote activating device to the door unless it is located within the ”line of sight” of the door. Do Not use a fuse larger than specified.
  • Page 21 27” Push Arm FIGURE 1: SYSTEM COMPONENTS – PUSH ARM FIGURE 2: OPERATOR CLEARANCES – PUSH ARM FIGURE 3: MOTOR/GEARBOX & CONTROL BOX REMOVAL Reveal "B" "C" 1" 22" 27" 2" 21" 26" 3" 20" 25" 4" 19" 24" 5" 18"...
  • Page 22 27” Pull Arm FIGURE 5: SYSTEM COMPONENTS – PULL ARM FIGURE 6: OPERATOR CLEARANCES – PULL ARM FIGURE 7: MOTOR/GEARBOX & CONTROL BOX REMOVAL FIGURE 8: OPERATOR INSTALLATION – PULL ARM Installation and Arm Adjustment Notes: Remove the control box and motor/gearbox from the mounting bracket (Figure 7). Mounting bracket must be installed with the thread studs away from the hinge to ensure correct operator orientation.

  • Page 23: Full Length Push Arm

    and adjust the arm to the desired door position together with the track. Once the desired position has been chosen, tighten the 8mm socket head screw. Remove the jumper wire. Snap the end caps into the cover and secure with the (2) 6-32 round head screws provided. Snap in the optional end cap insert (provided in the screw bag) on the end cap opposite the on/off switch.

  • Page 24: Full Length Pull Arm

    Reveal "B" "C" 0" 23" 28" 1" 22" 27" 2" 21" 26" 3" 20" 25" 4" 19" 24" 5" 18" 23" FIGURE 13: OPERATOR INSTALLATION – PUSH ARM 6" 18" 23" Installation and Arm Adjustment Notes: Remove the control box and motor/gearbox from the mounting bracket (Figure 11). Center operator over opening (Figure 12) Mounting bracket must be installed with the thread studs near the hinge to ensure correct operator orientation.
  • Page 25 FIGURE 16: MOTOR/GEARBOX & CONTROL BOX REMOVAL FIGURE 17: CENTERING OPERATOR OVER OPENING FIGURE 18: OPERATOR INSTALLATION – PULL ARM 99101-084 Rev E February 2003 Page 9 of 15...

  • Page 26: Double Push Arm

    Installation and Arm Adjustment Notes: Remove the control box and motor/gearbox from the mounting bracket (Figure 16). Center operator over opening (Figure 17). Mounting bracket must be installed with the thread studs away from the hinge to ensure correct operator orientation. Mount switch bracket as shown (Figure 18).

  • Page 28: Low Ceiling Application

    Installation and Arm Adjustment Notes: Remove the control boxes and motor/gearboxes from the mounting brackets (Figure 21). Mounting brackets must be installed with the thread studs near the hinges to ensure correct operator orientation. After installing the mounting brackets on the header or frame, install the motor/gearbox onto the studs with the 4 nuts provided and then install the control box onto the mounting bracket with the 2 flat head screws provided.

  • Page 31: Troubleshooting

    Troubleshooting If door does not open at all, ensure door is not locked and power is on. If door is unlocked and power switch is on, check fuse(s), circuit breaker, and connections. Use the following procedure. 1. Standard Control Box. Adjust the pots to settings below.
  • Page 32 Dor-O-Matic Benchmark Extended Reveal Kit and Extended Reveal Assembly for 10" Reveal (maximum) Figure 1 Figure 2 95005-000 shown with 95025-1XX Arm Extension 95025-9XX Extended Arm Assembly Figure 3 Figure 4 1. Refer to 99101-084 Benchmark Installation Instructions for installation of operator onto door frame.
  • Page 33 BENCHMARK TROUBLE-SHOOTING CHART For Standard Benchmark control boxes mfg after 12/1/03 and Premium control boxes mfg after 1/01/04 See Operators Manual (95299-084) and verify wire connects before trouble-shooting unit. PROBLEM TEST CAUSE SOLUTION Door will not open 1) Check 3-way (on-off-hold open Switch is in off position.
  • Page 34 BENCHMARK TROUBLE-SHOOTING CHART See Operators manual (99101-084) and verify wire connects before trouble-shooting unit. PROBLEM TEST CAUSE SOLUTION Door will not open 1) Check on-off-hold open Switch is in off position. Place switch in "on" when activated switch and on-off switch. position.
