- Page 1 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual 4 Ports Mini-SAS Backplane User Manual Rev. 1.0 Supplier : Chenbro Micom Co., Ltd . Description : 4 Ports Mini-SAS Backplane Chassis : SR209/SR105/SR107/SR108/RM314 Part No : 80H102209-013 http://www.chenbro.com...
-
Page 2: Technical Support
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Chenbro Micom Co., Ltd. Information provided in this manual is intended to be accurate and reliable. However, Chenbro Micom Co., Ltd., assumes no responsibility for its use, nor for any... - Page 3 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual Category General Hard-Ware Specification 2 Backplane Layout 3 Backplane Photo 4 Backplane Cable Information 5 Backplane Ordering Information http://www.chenbro.com...
-
Page 4: General Hardware Specification
Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual General Hardware Specification Host Interface Mini SAS (SFF-8087) interfaces(single path) HDD connector (power+drive : 7+7+15 pins) for SAS HDD Interface (Serial Attached SCSI) drive , also compatible to SATA II drive (7+15 pins) - Page 5 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual 1. HDD activity LED source is selected by 2 x 5 pins headers “jumper setting” for : a. from pin 11 of HDD (As HDD support ) b. or external HBA Card by adapter wire 2.
-
Page 6: Backplane Layout
Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual Backplane Layout Backplane Connectors Front view (HDD slot In) CN41 CN31 CN21 CN11 http://www.chenbro.com... - Page 7 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual Rear View (Host Connector In ) JP1 JF1 CN2 CN1 CN5 [CN11/CN21/CN31/CN41] : 29-pins SAS HDD connector [CN7] : Min-SAS Host connector [CN3 /CN4] : Power connectors [CN1] : External HDD Activity LED Signal Input connector (from RAID Card)
- Page 8 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual Pin Assignment [CN1] HDD Activity LED Connector Def. HDD No. External Activity LED Signal CN11 Input CN21 (Remove jumper then plug CN31 adapter wire to connect CN41 RAID card) Key Pin 1 & 2...
- Page 9 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual [JP1] Redundant PSU Module Fail Connector Def. Power Fail Signal (TTL Active Low) [JM1] Alarm Mute Connector Def. Switch - Switch + [JC1] I2C Connector Def. [CN9] SGPIO Enable/Disable Connector Def. 1&2 close Enable - 1&2 open Disable...
- Page 10 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual Backplane Photo http://www.chenbro.com...
- Page 11 Chenbro SR209/105/107/108 4-Ports Mini-SAS Backplane User’s Manual Backplane Cable Information 1. Please refer to below compatible Mini-SAS cable for HBA HOST All of Mini-SAS cables are including SGPIO signal inside (Side Band) Item no. Description Part No. Photo Fig. No. Length...
- Page 12 HDD3 HDD2 HDD1 Compatible Chassis Model List Part No. Description Chassis Model SR209 (required 1 pcs) SR105 (required 1 pcs) 4 ports MINI-SAS Backplane with SGPIO/I2C 80H102209-013 functionality for HDD fail LED SR107 (required 2 pcs) SR108 (required 2 pcs)
