- Page 1 Glux IDsn ODsn Series Product Manual Glux Visual Effects Tech(Shenzhen)Co.,Ltd...
-
Page 2: Product Overview
1.4 tons. Ultra- 500mm thin design & lightweight.Only 17.2kg/ sqm. Modular design for convenient maintenance. SI/AC Panle Cable Power Supply Product Specifications Glux LED Display IDsn series Type IDsn2.6 IDsn3.9 IDsn5.2 IDsn7 Parameter Pixel Pitch (mm) Pixel Density (dots/m ) - Page 3 Glux LED Display ODsn series Type ODsn3.9 ODsn5.2 ODsn7 Parameter Pixel Pitch (mm) Pixel Density (dots/m ) 65536 36864 16384 128x128 96x96 64x64 Pixel / Panel (W*H) 4000 / 6000 4000 / 6000 6000 Brightness Max (cd/m ) Grey Scale (bit)
-
Page 4: Installation Diagram
Power Cable Neutrik-Neutrik(6m) Power Cable Neutrik-Glux(6m) Power Cable Neutrik-ODU(6m) For actual accessories and cables ,please select according to the product connector and installation way. Installation Diagram Hanging Installations Step1: Fasten installation clips Step2: Lifting LED display modules Step3: Connect the panels... - Page 5 Power/Signal Connection for LED Screen Power/ Signal Connection Diagram Power/ Signal Connection Impression Drawing To ensure the safety use, for single- Power connecting way shown as the red line, supply panels connected not Power Cable exceed 15 pieces, dual-power supply Signal Cable signal connecting way shown as the blue line.
-
Page 6: Safety Summary
Safety Summary Read the following safety precautions carefully to avoid injury and prevent damage to this product or any products connected to this product. To avoid potential hazards, use this product in accordance with regulations. Only qualified personnel can perform service procedures. 1. - Page 7 Glux Visual Effects Tech(Shenzhen)Co.,Ltd Nanshan OTC Eastern Industrial Park, Bldg.A4,Office 504, Shenzhen,Guangdong,China-Postal Code:518000 Tel:+86-755-88866999 Fax:+86-755-86241789 Glux Industrial Park.Donghuan 2nd Road,Longhua New District, Shenzhen,Guangdong 518109 P.R. China Tel： +86-755-29174931 Fax： +86-755-86232733 Set：www.glux.com.cn www.glux.cc...
