ReosMODS REO p67 User Manual

Getting Started:

REOs mods have several distinct components. In the picture to the right, you
can see the catch cup, 510 connection, and locking push button. The locking
push button is very important. Since the button is very easy to push when
unlocked, we strongly advice you turn the button clockwise into the locked
position before putting in pockets or purses.
In the picture below, you can see the juice bottle and cap with feed tube,
Delrin insert covering the positive contact, the spring, and magnets on top to
hold the door in place. Fill the juice bottle 3/4 full with your favorite juice
and install the bottle by screwing firmly into place.
Delrin Insert
Magnets
Bottle, Cap, Feed Tube
Congratulations on the arrival of your new REO!
We hope that this will be the last brand of personal vaporizers you will need
to buy. This device was designed by Robert E. O'Neill, a former smoker who
decided that the common e-cigarette wasn't up to his standards. He took
many aspects into consideration when designing this bottom fed juice APV
(advanced personal vaporizer), including: appearance, heft, durability,
simplicity, and safety. Today all REOs mods are built by Eric Parlin and
family, with the same high standards.
All metal REOs mods (P67, Grand, Grand LP, Grand LP/SL, Mini 2.1, Mini
2.1 LP, and Mini 2.1 LP/SL) are milled from block aluminum and are 100%
mechanical. This means there are no wires, resulting in a nearly indestructi-
ble unit that can take a beating, and a washing too, although we don't
recommend that.
Blow the primer out of your new atomizer, then screw it into the atomizer
connector. If your atomizer doesn't fire, you may need to adjust the center
post in the 510 connection using the hex key (Allen wrench) that came with
your mod. Turn the center post counter clockwise to raise the center post. Be
careful not to over tighten your atomizer; it should have a snug fit, but not
too tight. Prime your atomizer with 5-10 drops of juice and add the drip tip. If
you have noalox or deoxit on hand, we recommend applying a dab to your
positive contact because use. After installing the atomizer, insert your battery
Positive positive end up. Unlock the push button and slide your door into place. You
Contact
can now test your unit by pressing the push button and drawing on the drip
tip to make sure everything is working.
To feed juice, gently press (not pump) on the bottle until you see juice
appearing at the bottom of the atomizer in the catch cup. The first time you
feed the atomizer takes the longest. The time it takes for the juice to feed
Spring
from the bottle to the atomizer varies greatly depending on the makeup of
the juice. VG juice typically takes longer than PG juice, as it's a thicker liquid.
To increase the lifespan of your atomizers, it is recommended that you do not
"dry burn" them. It is a good idea to press the bottle to feed more juice before
your atomizer runs dry.
At this point, you should be ready to vape!
User Guide for Metal REOs
Locking Push Button
Catch Cup
510 Connection
Adjustable Center Post
