- Page 1 F F F F F S S S S S R R R R R INTRODUCTORY NOTES on the ML-116 THE NEW ROOM COMBINING SYSTEM 244 Bergen Boulevard, West Paterson, NJ 07424 Tel 973-785-4347 Fax 973-785-3318 E-Mail sales@fsrinc.com Web www.fsrinc.com...
- Page 2 F F F F F S S S S S R R R R R Page 2 Telephone 973-785-4347...
- Page 3 The ML-116 is the latest, enhanced version of the popular ML-112A . A microprocessor-based system, the ML-116 is capable of combining up to sixteen rooms in multiple configurations.Contractors appreci- ate the flexibility of the ML-116 which can be operated with a variety of mixers, equalizers and power amps.
- Page 4 F F F F F S S S S S R R R R R OVERALL VIEW OF SYSTEM COMPONENTS 2 GANG ML-116 WALLPLATE Page 4 Telephone 973-785-4347...
- Page 5 F F F F F S S S S S R R R R R 3 GANG ML-116 WALLPLATE Page 5 Telephone 973-785-4347...
- Page 6 H...This 3 pin connector may be used to provide lim- on the map panel. A...This 3 pin connector receives the audio signal from ited combining capability among multiple ML-116 sys- the ODD room's mixer. tems. B...This 3 pin connector receives the audio signal from the EVEN room's mixer.
- Page 7 J...The ML-116 regulator module accepts unregulated M...Test mode dip switches and test mode indica- DC voltages from the ML-116 PSA, power supply. tors. These are used at the factory and are not to be A plugable connection is provided to connect to the operated in the field.
- Page 8 These cards are driven by the A..There are two types of wallplates HTBC board. available for use in the ML-116 system , membrane E..The PSA Power Supply for the ML-116 and LCD. Both control all wallplate functions. These system.
-
Page 9: System Specifications
F F F F F S S S S S R R R R R SYSTEM SPECIFICATIONS Audio Control Unit (ACU) Audio Connections: RA2 Module (one per two rooms) Inputs: electronically balanced 20K Impedance (unbalanced 10K), 3 pin screw termi nals Outputs: 600 ohm transformer coupled (balanced) 3 pin screw terminals Audio Connections: MP Module (music/page module) - Page 10 Monitor Relay Card (supplied with the Monitor/VU card) Size: 3 1/4 inches wide, 9 1/2 inches long, 1 inch high, comes already mounted in a 19 inch FSR TRAC-BRAC Mounting: rear rack rails MLH Head Table Speaker Assembly (optional)
- Page 11 (MNRL); 3 1/4 inches wide, 9 1/2 inches long, 1 1/2 inches high Mounting: both the MNP and the MNRL cards come already mounted in a 19 inch FSR TRAC-BRAC Speaker: enclosed in an attractive baffle 7 inches high, 6 1/2 inches wide, 5 inches deep...
