CVS Controls Ltd. 67CFR Installation Instructions Manual

CVS 67CFR Pressure Reducing
Instrument Supply Regulator
INTRODUCTION
The CVS Controls 67CFR Filter regulator is a
pressure reducing supply regulator typically used
for pneumatic and electro-pneumatic controllers,
as well as other instrumentation equipment. The
CVS 67CFR provides constant, clean air or gas
supply to devices requiring reduced pressures for
control.
These Installation Instructions provide installation
and Start Up procedures for the CVS 67CFR
Regulator. Should additional maintenance or part
information be required, please refer to the
CVS 67 CFR Instruction Manual.
SPECIFICATIONS
Temperature – Nitrile Standard
-40 o C to 82 o C (-40
Maximum Inlet Pressure:
250 psig (17.2 bar)
Maximum Outlet Pressure:
50 psi (3.4 bar) over outlet pressure setting
Head Office
3900 101 Street
Edmonton, Alberta
T6E 0A5
Canada
Office: (780) 437-3055
Fax: (780) 436-5461
o F to 180 o F)
Website: www.cvs-controls.com
INSTALLATION INSTRUCTIONS
CVS 67CFR, Panel Mount
Vented Spring Case
CVS 67CFR Regulator with optional gauge
Outlet Pressure Ranges:
0 to 35 psig (0 to 2.4 bar)
0 to 60 psig (0 to 4.1 bar)
0 to 125 psig (0 to 8.6 bar)
Approximate shipping weight:
1 lb (.45 kg)
*Also available in Stainless Steel Panel Mount
