Hi-Lux PHENOM ED FIELD FLATTENED Instructional Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PHENOM ED FIELD
FLATTENED BINOCULARS
INSTRUCTIONAL MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PHENOM ED FIELD FLATTENED and is the answer not in the manual?

Questions and answers

Summary of Contents for Hi-Lux PHENOM ED FIELD FLATTENED

  • Page 1 PHENOM ED FIELD FLATTENED BINOCULARS INSTRUCTIONAL MANUAL...
  • Page 2 PHENOM ED FIELD FLATTENED CONGRATULATIONS! You have just target, whether you’re tracking big game or purchased our PHENOM ED Field Flattened birding. binocular; one of the best binoculars in its class. The Phenom ED binoculars deliver The Phenom ED binoculars enable its...
  • Page 3 No corners have been cut in the production demanded by the modern outdoorsman. of these binoculars. All glass lenses are Leatherwood/Hi-Lux committed meticulously polished to photographic manufacturing high quality optics that meet quality for exceptional clarity and light these demands.

  • Page 4: Table Of Contents

    PHENOM ED FIELD FLATTENED TABLE OF CONTENTS SECTION 1 : SPECIFICATIONS AND BASIC DEFINITIONS SECTION 2 : CUSTOMIZING YOUR PHENOM ED SETUP SECTION 3 : FOCUSING YOUR BINOCULARS SECTION 4 : MAINTAINING YOUR BINOCULARS SECTION 5 : DIAMONDTUFF GUARANTEE...

  • Page 5: Specifications And Basic Definitions

    BINOCULAR MANUAL SECTION 1 SPECIFICATIONS AND BASIC DEFINITIONS (1) SPECIFICATIONS: Close F.O.V.@ Interpupillary Obj. Focus Weight Twilight Model Power 1000 Yds Distance Luminosity (mm) Distance (O.Z.) Factor (Feet) (mm) (ft) PM8X42 421’ 56-74mm 4.9’ 18.33 27.0 PM10X42 342’ 56-74mm 4.9’ 20.5 17.6 All glass lenses are fully multi-coated with DiamondTuff14 to maximize the light...
  • Page 6 PHENOM ED FIELD FLATTENED (2) BASIC DEFINITIONS: A) Twist Up Eyecup; B) Center Focus Wheel; C) Strap/Harness Attachment; D) Locking Diopter; E) Tripod Adapter Socket; F) Objective Lens...

  • Page 7: Customizing Your Phenom Ed Setup

    BINOCULAR MANUAL SECTION 2 CUSTOMIZING YOUR PHENOM ED SETUP The eyecups of the Phenom ED binoculars are adjustable so that every viewer can comfortably look through these binoculars. Simply twist the eyecups counterclockwise to raise the eyecups. There are two set positions for the eyecups. Additionally, you can also adjust the Interpupillary distance (IPD) by rotating both barrels of the binocular inward or outward.

  • Page 8: Focusing Your Binoculars

    PHENOM ED FIELD FLATTENED SECTION 3 FOCUSING YOUR PHENOM ED BINOCULARS For the best results in the field, follow this three step procedure to properly adjust the center focus and diopter for your individual eyesight. Scan and find an object at least 10 yards away from you and stay in the same spot until you have adjusted the binocular for both eyes.

  • Page 9: Maintaining Your Binoculars

    BINOCULAR MANUAL eye diopter to lock this setting in place. 3) Use Center Focus Wheel to Fine Tune Focus - Keep both eyes open and adjust only the center focus wheel (if necessary) to fine tune the image sharpness. SECTION 4 MAINTAINING YOUR BINOCULARS Your binoculars, though amazingly tough, is a precision instrument that deserves reasonable and cautious care.
  • Page 10 PHENOM ED FIELD FLATTENED lens cloth provided or an optical/non-abrasive lens wipe. NEVER USE FACIAL TISSUE, HEAVY COTTON, OR FLANNEL CLOTH ON LENSES. THESE MATERIALS WILL SCRATCH AND DAMAGE THE LENSES. D. Keep the protective lens covers in place when the binoculars are not in use.

  • Page 11: Diamondtuff Guarantee

    United States. The warranty is transferable. Warranty obligation is limited to the repair or replacement of any product returned to Hi-Lux, Inc. that is determined by the manufacturer to have defects arising from faulty workmanship or materials that adversely affect the satisfactory operation...
  • Page 12 Hi-Lux provides a two-year warranty for the electronic components that are contained on the products. Hi-Lux, Inc. reserves the right to request proof of purchase and purchase date. Hi Lux assumes no liability for any incidental or consequential damages, theft, or incidental expenses.
  • Page 13 BINOCULAR MANUAL All returns are to be shipped prepaid direct to Hi-Lux, Inc. including a check or money order in the amount of $21 to cover postage and handling. Additional fees will be applied to all returns from outside the continental United States.
  • Page 14 Leatherwood @leatherwoodoptics /LeatherwoodHiLuxOptics @HiLuxOptics hi-luxoptics.com...
