- Page 1 DIGIT L MMETER Operating & Instruction Manual HVA-2000 1475 Lakeside Drive • Waukegan, Illinois 60085 U.S.A. • 847.473.4980 f a x 8 4 7 . 4 7 3 . 4 9 8 1 • w e b s i t e : w w w. H D E l e c t r i c C o m p a n y. c o m...
- Page 2 500kV. The HVA-2000 measures current from 1 Amp up to 2000 Amps and current is displayed in the large easy to read four digit display.
- Page 3 SAFETY • Only trained, professional operating personnel should use the HVA. The voltages this instrument operates at are dangerous and lethal. Severe injury or death can occur if improperly used. • Risk of electrocution is inherent in or around high voltage. •...
- Page 4 U, the current reading is displayed. Up to four current measurements are stored by the HVA-2000, sufficient to measure three phase conductors and a neutral. To display the stored readings, press the ON button for each reading. Each of the four readings will be displayed in rotation.
- Page 5 MEASURING CURRENT ON UG CABLES & IN PADMOUNT ENCLOSURES Secondary voltage cables are generally unshielded and current can be easily measured by placing the HVA completely over the secondary cable or cable bundle so that all cables are completely inside the U on the HVA. Primary voltage cables are generally shielded and the HVA cannot measure current on a shielded cable except in areas where the shield has been removed.
-
Page 6: Specifications
SPECIFICATIONS MODEL NUMBER: HVA-2000 OPERATING VOLTAGE RANGE: Up to 500kV line to ground OPERATING FREQUENCY: 25-500Hz OPERATING TEMPERATURE RANGE: -40F to +120F (-40° to 49°C) DIMENSIONS: 4”H x 6.6”W x 11.5”L (10 cm x 17 cm x 29cm) WEIGHT: 1.8 lbs. (0.8 kg) LED HEIGHT: 1.5”(3.8 cm) - Page 8 LIMITED WARRANTY AND LIMITATION OF LIABILITY This warranty applies to all products sold by HD Electric Company (the "Products"); provided, however, that the term Products does not include any third party products purchased through HD Electric Company, for which no warranties are made (the "Third Party Products"). Third Party Products may be subject to a separate manufacturer's warranty;...
