The EDS model "A" operates with a standard aviator's nasal cannula for single person flight
operations up to 17,999 ft. or a face mask for flight operations over 17,999 ft. and up to
30,000 ft. Both of these items are included with each EDS kit. Several EDS units can share
a single cylinder and primary reducing regulator for multi-place operations.
refer to FAR 23.1447 to see if any restrictions apply for their use of cannula type breathing
devices in the operation of their aircraft.
physiology is constantly changing and updated. Therefore, Mountain High E&S Co. reserves
the right to correct and enhance this manual and associated documentation at any time
without notice.
Mountain High Oxygen systems are designed to contain and deliver pure oxygen for the
purpose of supplemental breathing as needed for exposure to high altitudes. They are not
intended for medical or underwater use. Pure oxygen is a highly oxidizing gas in nature and
vigorously accelerates combustion. It can provide a catalyst for spontaneous combustion if
not used properly and with caution. DO NOT use any type of oil or grease on any of the
fittings, valves or cylinders. DO NOT use the system while smoking or near an open flame.
M H
Aviation Oxygen
Management Systems
625 SE Salmon Ave, Redmond, OR. 97756
Tel: 541-923-4100
Operation Manual
for the
E D S
Electronic Oxygen Delivery System
Analog Computer Model A-1
NOTICE
BASIC SAFTY
Fax: 541-923-4141
R 3.7
Information and data in the field of flight
Pilots should
Advertisement
Summary of Contents for MH EDS A-1
- Page 1 Operation Manual for the E D S Electronic Oxygen Delivery System Analog Computer Model A-1 NOTICE The EDS model "A" operates with a standard aviator's nasal cannula for single person flight operations up to 17,999 ft. or a face mask for flight operations over 17,999 ft. and up to 30,000 ft.
- Page 2 EDS front panel controls and indicators Oxygen inlet Oxygen flow Oxygen outlet External power input jack on tube indicator LED tube Mode top of EDS unit (not visible) switch Highpressure reducing regulator for portable Flow fault applications Power ON/OFF Battery test switch button Static air...
- Page 3 The main objective of the EDS was to provide an improvement The EDS (Electronic oxygn Delivery System) is a single in oxygen conservation, allowing a smaller and lighter oxygen person aviation oxygen delivery system designed to maximize system, allowing existing cylinders to last longer or to allow the administration of oxygen in the most efficient way.
- Page 4 Basic EDS assembly & installation instructions The EDS delivery package comes with the following equipment and should have the following equipment and parts. Please contact your dealer or Mountain High direct if there is any part of this kit damaged or missing. 1 ea.
- Page 5 To remove the polyurethane service line you must push in the The EDS system parts connector collar while you pull on the polyurethane line. Do not pull the polyurethane line without pushing in the collar. It The polyurethane service line is 5/32" (4 mm) O.D. This gives will damage the connector.
- Page 6 To test the EDS unit for readiness follow these steps: The flow fault alarm will respond to the following actions or reasons: If the EDS unit fails these simple tests, please be sure that you 1: If you inhale on the system without a supply of oxygen have a fresh battery installed, that your supply of oxygen is 2: If you try to inhale from the system directly without indeed connected and all tubes are connected correctly and not...
- Page 7 Service, maintenance & care of the EDS unit model A With the exception of the electromechanical valve, While not being used the EDS unit should be stored in a secure mechanically operated switches and buttons, there manner to ensure that dirt and debris do not enter and become are no parts or sensors inside the EDS that will lodged in the inlet and outlet tubes.
- Page 8 EDS APPLICATION NOTES for various emergency oxygen back-up bypassing methods The EDS has proven to be a very reliable oxygen delivery device used by many in various types of aviation and has no means inside itself to provide a by pass of oxygen in the event of a total failure.
- Page 9 Part ref Part description C1, C6 10.0 ufd/15 VDC Tant. C2, C4, C5 0.1 ufd/50 mono. 1.275 K Ohm 1% 220 Ohm 1% 1N4001 T1, T2 MH-T250 (supplied by Mtn. High E&S Co.) LM317 precision programmable voltage regulator.
-
Page 10: General Specifications
General Specifications This is a list of specification parameters for the EDS model "A" with calibration schedule "D". These specifications are operational and performance standards (or limits) against which the EDS was tested or calculated. Specifications are subject to change without notice. Operating Voltage &... - Page 11 * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * Limited Lifetime Warranty &...
