Keyboard Follow; Polyphony - Cascading Multiple Lite Ii Modules - MFB SYNTH LITE II Operator's Manual

Keyboard Follow

Octave(OSC2)
Release = Decay
Wave(OSC2) 0 = OFF
MIDI In/Out
Glide/Shift 0 = Thru 1 =ProgChg 2 = ConChg
Mod. Wheel
Wave(Mod) 0 = Off

Polyphony - Cascading multiple LITE II modules.

----------------------------------
Although each SYNTH LITE II is monophic, up to five modules can be cascaded to act as a
polyphonic synthesizer. Connect the keyboard /sequencer to the first module and chain
the following modules in series. This is how it works: The last LITE II will play all
incoming MIDI notes, the second last has to play every second note and send out the
other one, the third plays every third note and sends the other two notes and so on.
Switch on your Lite II modules while holding:
• OCTAVE (OSC1)
(This is the standard setting)
• WAVEFORM (OSC 1)
• OCTAVE (OSC2 )
• WAVEFORM (OSC2)
• GLIDE
Tip: You can try to use other keyboards in the last position to split polyphonic sounds
across different modules.
0 = Off 1 = ¼
1 = ADSR1
1 = VCO
this LITE II will play all notes
this LITE II will play every second note and
send the other to its MIDI output
this LITE II will play every third note and send
the others to its MIDI output.
this LITE II will play every fouth note and send
the others to its MIDI output.
this LITE II will play every fifth note and send
the others to its MIDI output.
2 = ½ 3 = ON
2 = ADSR2 3 = ADSR1+2
3 = both
2 = VCF 3 = VCO/VCF
