USBGEAR USBG-4PminiH Manual

USBG-4PminiH USB 3.0 Metal Mini 4-Port Hub
The USBG-4PminiH has been designed to be connected a computer with USB interfaces.
It serves to connect additional USB devices. During operation it operates like a bi-
directional repeater, which repeats USB signals as required on upstream
(computer) and downstream (peripherals) cables. It is designed for USB 3.0 and
backward compatible with USB2.0 and USB 1.1. Its operation requires connection
with a computer. Only operate the USB HUB in dry indoor room.
Unauthorized conversion and/or modification of the device are inadmissible
because of safety and approval reasons (CE). Such acts invalidate the warranty.
Any usage other than described above is not permitted and can damage the device and lead to associate risks such as
short-circuit, fire, electric shock and etc. Please read the operation instructions thoroughly and keep the operating
instructions for further reference.

Features

• USB 3.0 4-Port Super-Speed Hub
• Fully compatible with USB 2.0/3.0/1.0
specification
• Fully backwards compatible with USB 2.0/1.1
specification
• Supports Transfer rate of 5Gbps/1.5/12/480
Mbps
• 900mA each port is reliable up to 15 feet of
transmission
• Support Self-Powered Mode
• Support Hot plug and play

Technical Data

Input voltage:
USB standard
Connections:
Transfer rate
Cable Length
Operating temperature
Storage temperature
Dimension(W x H x D):
Weight:
System requirements
5V/ DC, 900mA ( without power supply unit，USB 3.0)
5V/ DC, 500mA(with power supply unit，USB 2.0)
5V/DC , 4000mA(with power supply)
3.0 / 2.0 / 1.1
4 x USB 3.0 , 1 x micro USB 3.0 B-type
5 GBit/s
1m
-5℃ to 45℃,20~80%
-10℃ to 60℃,20~80%
122 x 20 x 44 mm
110g(hub)
Windows® XP, Vista,7, MacOS® 9 or higher
Sales@usbgear.com
•
One Upstream port
•
Four Downstream ports
•
One LED to indicate Hub is ready
•
Four LEDs to indicate per port status
•
Downstream ports have automatic connect and
speed detection function plus over-current
protection with auto recovery
•
Compatible with Windows
7/8/10/98/2000/XP/2003/Vista Mac OS X
•
Dimensions: 4.8 x 1.7 x 0.8 inches / 121.92(L) x
43.18(W) x 20.32mm(H)
