- Page 1 OLIVIA SEWING CABINET OWNER’S MANUAL Where Creativity Meets Color! Assembly Instructions Model Numbers: 1001 White 1004 Pistachio Green 1009 Blue IMPORTANT: Please read these instructions before assembling!
- Page 2 READ THIS PAGE FIRST ARROW WARRANTY Thank you for your purchase of an Arrow Sewing Cabinet! Thank you for your purchase! Our products have a three-year warranty from the date of shipment from our facility that covers manufacturer defects plus a 15 day warranty for any shipping damages.
- Page 3 • Production ID Number 1-800-533-7347 • Number of Part Required Arrow Cabinets • Your Name, Address, and Phone Number P.O. Box 307, Delavan, WI 53115 TO ORDER REPLACEMENT PARTS CALL 1-800-533-7347 Wooden Materials Parts are labeled with capital letters.
-
Page 4: Hardware Included
Hardware Included Connecting Bolts x32 Cams x32 Drawer Runners x4 #6x1” Drawer Connecting Bolts x4 Drawer Cams x4 Flathead Screw x16 #10x1-3/8” Wood dowel 8x30mm x16 Wood dowel 6x30mm x16 Door Knob x2 Door Knob Bolt x2 #10x1-1/4” #7x5/8” Flathead Screw x8 Flathead Screws x2 Metal Dowels x2 Drawer Stoppers x2... -
Page 5: Cabinet Assembly
Understanding How the “ARROW-LOC” Cam Fastener Works 180° ARROW TOWARDS HOLE IN EDGE! Position bolt in Press cam Into pre-drilled Insert bolt through pre-drilled To lock, rotate cam pre-drilled hole and hole until flush with surface. hole in edge of panel. - Page 6 Step 2. Attach drawer runner (x1) each to Cabinet drawer runner using #7x5/8” Flathead screws Side Panels (C), (D), (L) and (M) using #6x1” (x2). DO NOT tighten the screws completely, leave Flathead Screws* (x16) (See FIG 2). Screw Drawer 1/4”...
- Page 7 Panels (C, M). With the curved edge facing the legs on Step 4. Insert 6x30mm Wood Dowels (x8) into each Panels (C, M), guide Straight Gingerbread Piece (J) into Straight Gingerbread Piece (J) and 6x30mm Wood Panels (C, M) (As shown in FIG. 4). Dowels (x4) into each Cabinet Side Connector (K) Note: For added support, drop 2 to 3 drop of wood (See FIG 4A).
- Page 8 Step 6. Panel (E) and (F). Also guide the dowels of (K) and Using two people attach Inside Side Panels (D, L), with Cams facing down, guiding the (J) into the dowel holes on Panels (D, L) (As shown connecting bolts into the holes on the edges of in FIG.
- Page 9 Step 8. With the Cams facing back attach Cabinet edge of (B) (As shown in FIG. 8) and tightening the Connector Panel (B) to Side Panels (D) and (L), Cams (x4). guiding the connecting bolts Into the holes on the FIG.
- Page 10 Step 10. Thread Drawer Connecting Bolts (4 total) Step 11. Attach Drawer Sides (O,Px2) to Drawer into pre-drilled holes and in Drawer Front (G). Front (Gx2), guide Connecting Bolts into holes in Insert 6x30mm Wood Dowels (x4) into each Drawer Drawer Sides (O, P), turn Cams to locked position.
- Page 11 Wood Parts and Part Numbers Cabinet Connector Panel Table Top with Sewing Cabinet Back Panel Cabinet Bottom Panel Machine Lift Assembly Cabinet Left Inside Panel Cabinet Left Outside Panel Cabinet Right Outside Panel Cabinet Right Inside Panel Side Connector Straight Gingerbread Drawer Side Right Drawer Front Piece...
- Page 12 Hardware Included with Part Numbers Cams Drawer Runners Connecting Bolts #10x1-3/8” Door Knob Bolt Drawer Cams Door Knob Drawer Connecting Bolts #6x1” Flathead Screw Wood dowel 8x30mm Wood dowel 6x30mm Item Description Part No. #7x5/8” Flathead Screws Cams 000709 Connecting Bolts 000709 Drawer Stoppers Drawer Cams...
- Page 13 How to Use the Mechanism in your new Olivia Sewing Cabinet Olivia offers two positions on her sewing surface, the freearm or up position and the flatbed or down position. Freearm/Up Flatbed/Down 1. To lower the platform down into the sewing well, press firmly down on the handle release and all the way back.
- Page 14 3. Never move the platform with your sewing machine on the platform. Always remove the machine as you move the platform up or down. To adjust the height of the platform in the second position creating a flush surface: 1. Move the platform down into the sewing well as demonstrated in step 1 above. 2.
- Page 15 A. TO LOWER PLATFORM: Remove your machine from the platform and pull the handle forward to lock the platform in the up position. B. Begin to loosen the bolt on the Eye-Hook located at the end of the chain under the top surface, until you achieve the proper height for your sewing machine.
-
Page 16: Troubleshooting
TROUBLESHOOTING 1. What should I do if my handle release falls off? If your handle release comes loose, reattach it by clipping it back into place. 2. Why does my sewing machine slam into the down position whenever I place it on the wood platform? The handle release was not locked into position when it was moved from the down to up position. - Page 17 Enhance your sewing experience with a custom-made Our sewing chairs are designed to provide comfort, insert for your Arrow or Kangaroo cabinet. Inserts are support, and the fashionable look you want for your designed to reduce the gap between the machine space.
