ATI Technologies LED Powermodule User Quick Reference Manual

1
Pushes current chart
configuration to the fixture
2
Allows you to save and
load light profiles to and
from your computer
3
Pulls last saved chart
from the fixture
4
Changes graph options
to allow for fine-tuning
of your program
5
Allows you to apply one
lamp's settings to any/all
lamps of that type
NODES
6
7
Pulls preset colors Adds a node to the
from the color menu left of the currently
to change nodes selected node
If you're having trouble with the ATI LED Powermodule, do not return to your retail dealer. Contact ATI Customer Care at customercare@atinorthamerica.com or (303) 459-2119.
LED Powermodule Quick Reference
1 2 3 4
8
Removes the currently
selected node
5 6 7 8 9
PREVIEW
9 10
Adds a node to the Plays a preview of
right of the currently the current program
selected node displayed on the graph
10 1 1 12
11 12
Pauses preview Stops preview,
where it is resetting it back to
the beginning
