User's Guide:
Fluidized Filling System
45490 Ruritan Circle
Sterling, Virginia 20164
703.964.0400
info@matsys.com
www.matsys.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fluidized Filling System and is the answer not in the manual?

Questions and answers

Summary of Contents for MATSYS Fluidized Filling System

  • Page 1 User’s Guide: Fluidized Filling System 45490 Ruritan Circle Sterling, Virginia 20164 703.964.0400 info@matsys.com www.matsys.com...
  • Page 2: Table Of Contents

    Table of Contents • Introduction • Fluidized Fill Shoe • Control Cabinet • Fluidization Principle • System Set-up and Installation • Gas Supply • Fluidizer Control • Mounting the Shoe • Connection to Control Cabinet • Initial Set-up • Check-out Procedure •...
  • Page 3: Introduction

    INTRODUCTION The MATSYS Fluidized Fill Shoe System (FFS) is a powder delivery system designed for consistent, fast and uniform filling of small die cavities. It can be used on a wide variety of particulate materials. The FFS system includes a fluidized fill shoe and a control cabinet.
  • Page 4: Control Cabinet

    1. Transport tube. The transport tube provides the connection between the particulate material supply hose and the delivery chute. It begins the process of conditioning the particulate material to a fluidized or loose state and conveys the particulate material to the delivery chute. 2.
  • Page 5: Fluidization Principle

    FFS BASIC PRINCIPLE Powder flows like a fluid when supported by a column of gas. The result is a reduction in the effects of head pressure, clumping and surge, both of which are common in gravity fed systems. The fluidized fill shoe creates a low pressure gas bearing below the powder inside the shoe to reduce the friction along the powder path to the fill point.
  • Page 6: System Setup And Installation

    SYSTEM SETUP AND INSTALLATION 1. Gas Supply The most optimal method of fluidizing is to use an inert gas such as Argon, alternatively compressed air can be used when properly treated, dried and filtered. When a compressed air source is used to supply air pressure to the fluidized fill shoe, the gas control supply pressure should be between 30 and 60 psi.
  • Page 7: Fluidizer Control

    Figure 2. It is recommended that the customer air supply line be plumbed as shown with a vertical inlet pipe to separator, trap, and drain valve. 2. Fluidizer Control Fluidization ‘ON’ / ‘OFF’ control is used to optimize the filling process. To use fluidization ‘ON’...
  • Page 8: Mounting The Shoe

    fill shoe centered over die cavity “dwell time” solenoid fill shoe movement rate relative degree Figure 3. Typical fluidized fill shoe solenoid timing chart, “continuous off.” 3. Mounting the Shoe on the Press Mounting the fluidized fill shoe on the press is a simple procedure. However, it is important to strictly observe the following mounting requirements: 1.
  • Page 9: Connection To Control Cabinet

    The fluidized fill shoe should follow a reproducible path for each stroke. This can be observed by sprinkling some excess powder around the die opening and observing the powder wipe trail during each stroke of the shoe. If there is excessive lateral or axial play in the fluidized fill shoe retraction mechanism, the shoe will wander as it moves in and out.
  • Page 10: Checkout Procedure

    6. Verify that you get approximately the same flow values as those printed in the “Fluidizer Gas Calibration Chart”. If you experience problems obtaining similar values to those given in the chart, contact MATSYS before proceeding. Otherwise you are ready to operate the fluidized fill shoe.
  • Page 11: Operation

    7. Operation For first time use you should adjust the gas pressure regulator and flow meters as follows: 1. Connect powder hose from hopper to transport tube. 2. With particulate material in the fluidized fill shoe, set the gas pressure regulator to a minimum of 0.25 psi.
  • Page 12 If cleaning the fluidizer porous plate in the described manner does not remove the contamination, the plate may need to be repaired or replaced. In this case it is recommended that the fill shoe be returned to MATSYS for service.
  • Page 13: Calibration Chart A

    Fluidizer Gas Calibration Chart A Transport Delivery Pressure Tube Loop (psi) (SCFH) (SCFH) 0.25 0.75 Gas Type: Length of Tubing: 6 feet Delivery Chute Type: PTFE Loop Transport Rating: 5 micron...
  • Page 14: Appendix A - Quick Reference

    APPENDIX A QUICK REFERENCE PROPER OPERATION OF THE FLUIDIZED FILL SHOE Before connecting the hose from the hopper to the fill shoe (with no material in the fill shoe) 1. Check desiccant: • Desiccant dryer color should be blue. If color is pink replace desiccant. 2.
  • Page 15: Appendix B - Operation

    APPENDIX B FFS OPERATION Once the fluidized fill shoe is mounted on the press and proper operation is verified, it is important to periodically check the fluidized fill shoe performance during extended production runs. The following chart summarizes the fluidized fill shoe operational readiness checks along with the recommended time periods between checks.
  • Page 16 FLUIDIZER GAS FLOW SET POINT – The fluidizer gas flow Before each run settings should be checked to verify that they are at the correct values. See factory calibration values below. WEAR PLATE The wear plate around the chute Before each run opening should lay flat along the press table with no gaps.
