Farnell L80AP User Manual

Tft lcd monitor 8.0” and 10.1”
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TFT LCD MONITOR
USER MANUAL
L80AP - 8.0" and L101AP - 10.1"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L80AP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Farnell L80AP

Summary of Contents for Farnell L80AP

  • Page 1 TFT LCD MONITOR USER MANUAL L80AP - 8.0” and L101AP - 10.1”...

  • Page 2: Table Of Contents

    Table Of Contents Table of contents/ Warning…………………………………………………………..….…2 Precautions …………………………………………………………………………....3 About this user manual and products / Items included in the delivery ……….…...….…4 1. IR-remote control ………………………………………………………………..…..……..5 2. Monitor controls …………………………………………………………………...…..……6 3. Connections..………………………………………………………………………..…..7 4. Monitor settings via OSD menu ……………………………………………………..……8 4.1 Picture ………………………………………………………………………………..…….8 4.2 Audio …….………………………………………………………………………….……...8 4.3 OSD...

  • Page 3: Precautions

    Precautions Safety--------------------------------------- Installation--------------------------------------- Should any liquid or solid object fall into the Do not install the unit in an extremely hot or cabinet, unplug the unit and have it checked humid place or in a place subject to excessive by the qualified personnel before operating it dust or mechanical vibration.

  • Page 4: About This User Manual And Products / Items Included In The Delivery

    Improper handling or usage of the appliance will invalidate the warranty. About these products (1). L80AP and L101AP 8.0” / 10.1” LCD TFT Professional Monitor LED Back Light, Resolution: (8”) 1024x600 (10”)1280x800, Inputs of Full HD HDMI, VGA, Composite video BNC, Audio with Speaker, Image reverse Up/Down, 12volt operation.

  • Page 5: Ir-Remote Control

    1. IR remote control (1). Power: Press this button to turn the monitor on/off. (2). Zoom: Press this button to toggle between the different picture formats: Full/Zoom1/Zoom2/4:3(16:9) (3). Mute: Press this button to disable the sound. Press this button again to turn the sound on again. (4).

  • Page 6: Monitor Controls

    2 Monitor controls (1). IR (2). LED (3). Power Turn the monitor on/off. LED: Green Monitor on LED: Red Standby mode (no input signal) (4./5). Adjust Up / Down ▲/▼ Increase or decrease the values in the OSD menu: Up: Increase the values. Down: Decrease the values.

  • Page 7: Connections

    3. Connections (1).Regulated DC12V Power Input 2.1mm (Positive centre). (2).Full-HD input - HDMI (3).VGA input - 15 pin Sub-D (4).Composite Video input -BNC (5).Audio input – 3.5mm stereo jack socket. (6).USB Warning: For firmware update only. (Do NOT connect other equipment to this socket or Damage will occur.) NOTE: Connections of Audio...

  • Page 8: Monitor Settings Via Osd Menu

    4. Monitor settings via OSD menu Various monitor settings can be made using the OSD menu (On Screen Display). Press the Menu/OK button to call-up the OSD main menu. Here you can make adjustments to the following items: Picture Audio Function Geometry Use the ▲/▼...

  • Page 9: Osd

    4.3 OSD (For Source: Composite Video / HDMI / VGA) ▲▼ buttons to select adjusts item, Use the and press source button to confirm. ▲▼ buttons to increase/decrease the values, Then use the or use “source” button to change the values. Press the menu button to return to the previous menu item.

  • Page 10: Geometry

    4.6 Geometry (For Source: VGA) ▲▼ buttons to select adjusts item, Use the and press source button to confirm. ▲▼ buttons to increase/decrease the values, Then use the or use “source” button to change the values. Press the menu button to return to the previous menu item. Item Description ▲▼...

  • Page 11: Technical Specifications

    6. Technical specifications Monitor model L80AP L101AP System PAL / NTSC LCD panel 8“ 10.1“ Visible area (mm) 176.64x 99.36 216.96x135.6 LCD Profile Ratio 17:10 16:10 Max. resolution 1024x600 1280x800 Pixel dot pitch (mm) 0.1725 x 0.1656 0.0565 x 0.1695 Colours 16.2M...
  • Page 12 Appendixes Troubleshooting The tables provided below include some problems that the user may encounter while using the display and the corresponding solutions. Please refer to the contents of this section prior to contacting service personnel. Problem Possible Causes Solutions 1. Is the power cable connected to the 1.

This manual is also suitable for:

L101ap
