EKO MC-11 Instruction Manual

4-20ma signal converter for pyranometers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MC-11
INSTRUCTION MANUAL
4-20mA Signal Converter
for Pyranometers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-11 and is the answer not in the manual?

Questions and answers

Related Manuals for EKO MC-11

Summary of Contents for EKO MC-11

  • Page 1 MC-11 INSTRUCTION MANUAL 4-20mA Signal Converter for Pyranometers...

  • Page 2: Table Of Contents

    7 - 1 . Tr ansd uc er Sp eci f ic a ti on 7 - 2 . D ime ns ions 7 - 3 . Acc es s o r i es L is t APPENDIX A-1. Optional Items Pg. 1 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 3: Contact Information

    For warranty terms and conditions, contact EKO or your distributor for further details. EKO guarantees that the product delivered to customer has been verified, checked and tested to ensure that the product meets the appropriate specifications. The product warranty is valid only if the product has been installed and used according to the directives provided in this instruction manual.

  • Page 4: Environment

    2. RoHS Directive 2002/95/EC EKO Instruments has completed a comprehensive evaluation of its product range to ensure compliance with RoHS Directive 2002/95/EC regarding maximum concentration values for substances. As a result all products are manufactured using raw materials that do not contain any of the restricted substances referred to in the...

  • Page 5: Ce Declaration

    EMC-directive: 2004/108/EC Date: July. 1, 2015 Position of Authorized Signatory: Deputy General Manager of Quality Assurance Dept. Name of Authorized Signatory: Shuji Yoshida Signature of Authorized Signatory: Pg. 4 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 6: Safety Information

    2. Power Supply  Always check the voltage and AC/DC type for the specified supply power before connecting the MC-11. If wrong type of power supply is connected, it may cause MC-11 malfunction and lead to accidents.  Use with fuse around 0.5A connected in series on the power supply cable. Depending on the power supply connected, large current may flow when the internal malfunction occur, and may lead to generating heat and fire.

  • Page 7: Introduction

    4. Introduction 4-1. Main Functions Pyranometer Signal Converter MC-11 is a compact signal converter which converts the voltage signal output (mV) from sensors like pyranometers into current loop signal output (mA). The output range of the current loop is between 4 to 20mA; 4mA is equivalent to 0W/m , 20mA is equivalent to 1,600W/m of solar irradiance.

  • Page 8: Package Content

    4-2. Package Contents Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately. Table 4-1 Package Contents Standard Items Qty. Remarks 4-20mA Signal Converter 1 unit L-Shaped Tab Terminals (Male) 4 pcs. Plug-Type Crimping Terminals 4 pcs.

  • Page 9: Getting Started

    NTC Thermistor Connection Terminal NTC Thermistor Connection Terminal 4-20mA Output & Power Supply Input Terminal ( - ) 4-20mA Output & Power Supply Input Terminal ( + ) Grounding Terminal Pg. 8 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 10: Setup

    5-2. Setup 1. Installation Install MC-11 in dry location (where it will not get wet or get soaked in water). Keep MC-11 away from direct sunlight. When fixing the MC-11 to mounting plate, use provided Double-Sems Screws for installation. Maximum torque for fastening the MC-11 to mounting is 0.4N/m.
  • Page 11 Pg. 10 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 12: Measurement

    = Shunt Resistance Value [Ω] = Maximum Irradiance Setting Value* (Default value: 1,600W/m *The maximum irradiance setting value can be changed using optional converter configuration cable and Configurator Software. Pg. 11 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 13: Troubleshooting

    4mA output show due to pyranometer zero-offset effects. (minimum 3.8 mA) Signal converter output is Check for any loose wire/cable connections. unstable. Confirm that the pyranometer is connected. Pg. 12 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 14: Specification

    Temperature Range, the measurement error may increase. *2 The recommended power supply voltage is 24V. *3 The maximum resistance value is 500Ω when the power supply voltage is DC 24V. Pg. 13 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 15 7-2. Dimensions Unit in mm Figure 7-1. Dimensions Pg. 14 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 16 Signal Converter Box 1 Mounting Feet, 3pcs Blind Bar) Box for 2 units of signal converter (Includes: 4pcs M4 screws, Signal Converter Box 2 4pcs Mounting Feet, 4pcs Blind Bar) Pg. 15 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...

  • Page 17: Appendix

    Windows XP, Vista, 7, 8, 8.1 License No limitation CPU: Applicable OS is operational Operation Memory: Applicable OS is operational Environment Hard Disk Capacity: More than 100MB Display Resolution: More than 800x600 Pg. 16 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 18 Installation Procedure Follow below procedure to install the Signal Converter Configurator Software: Download the latest version of Signal Converter Configurator Software from the EKO Website. MC-11 product page: http://eko-eu.com/ When the installer file is executed, following Welcome Window appears. Click [Next] button (Depending on the operating system, message for installation authorization may appear.)

  • Page 19: Eko Instruments Co., Ltd. 4-20Ma Signal Converter Mc-11 Instruction Manual Ver.5 Pg

    In the following window, click [Next] button to start the files required for the software to be copied to your computer Figure A-4. Confirm Setup Settings Window Pg. 18 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 20 Configurator Cable to No. 5 terminal on the Signal Converter. (Figure A-7) Figure A-6. Connection for Configuring the Signal Converter Figure A-7. Connection between the Signal Converter and Configurator Cable Pg. 19 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 21 Signal Converter Configuration Procedure Startup the software (EKO Sense Configurator). Initial setting of the language is English at the time of software startup. If necessary, change the language setting from the tool bar at the top of the window (Tools  Language). (There are English, Portuguese, Spanish, and Japanese available.) Figure A-8.
  • Page 22 The default setting values are as follows: <Serial Port Settings> Baud Rate：1200、Data Bits：8、Parity：None、Stop Bits：2、Handshaking：None <Line Signals> Non selectable <Data Mode> Big Endian Unicode <Serial Port Timeouts> Read Timeout (ms)：1000、Write Timeout (ms)：1000 Pg. 21 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 23 (i.e. 1600 W/m Settable range: 0 to +2000 W/m ・Offset Value: Offset for current loop signal (i.e. 0μV) Settable range: -1000 to +1000μA Figure A-12. Configuration Change Window Pg. 22 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 24 When there is already saved file available, this file can be loaded. Click [Open] button and select the XML file. The loaded configurations will be shown on the configuration window. Open Button Save As Button Figure A-14. Save and Load Configuration Pg. 23 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 25 Click [Advanced Option] button. Temperature correction and linearity correction functions can be setup by entering the following password: eko2014 Advanced Optional Settings Figure A-16. Advanced Optional Settings Pg. 24 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 26 I=(k1+(k2 x ETC(E,T)+(k3 x ETC(E,T)^2)+(k4 x ETC(E,T)^3))/S Where: Irradiance after Linearity Correction ETC (E, T) : Measurement Voltage after temperature correction mentioned above Pyranometer Sensitivity k1, k2, k3, k4 : Linearity Correction Coefficient Pg. 25 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 27 ・Minimum Irradiance: ・Maximum Irradiance: 1600 ・Offset Value: Optional Configurations: Linearity Correction ・k1: ・k2: ・k3: ・k4: Temperature Correction ・a: ・b: ・c: ・d: Load Default Button Figure A-18.Factory Default Setting Pg. 26 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 28 3. Signal Converter Box When MC-11 must be used in outdoor environment, optional metallic waterproof boxes with IP65 are available. There are converter box for 1 unit of Signal Converter (Converter Box 1) and box for 2 units of Signal Converters (Converter Box 2), which you can select to meet your needs. There are 3 cable glands (for running cables through the side of box) provided on the Signal Converter Box 1, and 4 cable glands on the Signal Converter Box 2.
  • Page 29 Converter Box 1 Converter Box 2 Figure A-22 Wiring Example of Converter Boxes Pg. 28 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 30 Dimensions Figure A-23. Converter Box 1 Figure A-24. Converter Box 2 Pg. 29 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 31 The installation feet hole pitches are as provided in Table A-6. Table A-6. Mounting Feet Installation Pitch Top & Bottom Hole Pitch Items Left & Right Hole Pitch Converter Box1 109mm 62mm Converter Box2 159mm 72mm Pg. 30 EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual Ver.5...
  • Page 32 EKO Asia, Oceania 1-21-8 Hatagaya, Shibuya-ku, Tokyo 151-0072 Japan P. +81.3.3469.6711 F. +81.3.3469.6719 info@eko.co.jp www.eko.co.jp EKO North America 95 South Market Street, Suite 300, San Jose, CA 95113, USA P. +1-408-977-7751 F. +1-408-977-7741 info@eko-usa.com www.eko-usa.com EKO Europe, Middle East, Africa,...
