B.A. International Ultimate BA101 Operation Manual

External Spray E-type
Contra Angle Handpiece
Operation Manual
The EU directive 93/42/EEC was applied in the design
and production of this medical device.
Ultimate BA101
9792837
Ultimate BA105
9792838
Ultimate BA105T
9792922
Thermo-Disinfectable
AUTOCLAVABLE
Caution before use
• The BA Brand Ultimate external spray contra angle handpiece is in-
tended for use by dental professionals only.
• Read this Operation Manual carefully before using the contra angle
handpiece. Be sure to follow all the operating instructions, including
all cautions and warnings.
• Keep this Operation Manual for future reference.
Specifications
Applicable Bur
Insertion/Removal
of Bur
Allowable Maximum
Speed
Nose Configuration
Sterilization
Note : The maximum speed may depend directly on the type of
tubing and type of motor.
Removal/Insertion of Bur from/into Contra
BA101
• Swing latch plate out. Remove the existing bur blank.
• Insert a bur into chuck hole all the way until the end of bur shank
touches the back of the chuck.
• Swing the latch plate back until it is fixed with a snap at the centre
position of the collar of the contra angle head.
BA105 and BA105T
• Push the pushbutton with thumb to open chuck, and then remove
the existing bur blank.
• Push the pushbutton with thumb, and then insert a bur into the
chuck hole.
• Release the pushbutton with thumb when the end of the bur shank
touches the end of chuck.
BA101
2.35 mm CA bur
Standard Latch Type
30,000 rpm
Autoclavable
Angle Handpiece
ENGLISH
Rev.2016/08
BA105
2.35 mm CA bur
Pushbutton Type
40,000 rpm
Autoclavable
BA105T
2.35 mm CA bur
Pushbutton Type
40,000 rpm
Autoclavable
Thermo-Disinfectable
