Page 1: User Manual
DT-ENG-AKP-V1 / 201701 2 WIRE SYSTEM DT-AKP Access keypad panel with scramble keypad User Manual RF CARD • Please read this manual carefully to ensure s afe and c orrect o peration. • K eep this manual well f or f uture reference. - Page 2 1.Parts and Functions [1] Front panel [2] Touch sensitive digital keypad [3] LED1 indicator [4] LED2 indicator [5] LED3 indicator [6] ID card window [7] Mounting hook [8] Connection port [9] Screw hole 2.Terminal Descriptions CN-LK SD Card Slot +12V •...
- Page 3 3.Mounting Use the screws to fix the mounting bracket to the wall. Connect the cable correctly. Attach the panel to the mounting bracket. Use the screwdriver and the screw to fix the panel. 4.Electric Lock Connection 4.1 Internal Power Supply Mode Use the power of the system to supply for the electronic lock, so that the lock can be connected to the access keypad panel directly, without an additional power supply for the electronic lock.
- Page 4 • The rated power of the lock must be less than 12Vdc 300mA when using internal power supply mode. • The GND must connect to the negative of the lock, and the COM connect to the positive . • The default unlock time is 3s. If different unlocking time is needed to be configured, change the Unlock Timing on access keypad panel.
- Page 5 D. Connection for Power--off-to-Unlock type: Set Unlock Relay mode to Normally Closed(1) +12V LK - (GND) LK+(COM) N.O. Note: Cut off this line when using external power supply EB - 5. Functions Setup This section explains the settings of each parameter,please refer to the following table: About the setting mode: Input the master code to enter the setting mode, and input the corresponding setting code to perform the settings for the function you want.
-
Page 6: Table Of Contents
Set unlock time 1 to 99 seconds 1 seconds Set unlock mode 0:opened/1:closed opened Set touch key prompt 0:flashing / 1: beep / mode 2:flashing + beep Reset code settings 1,2,3,4 &# function settings 0:Normal/1:Reverse Normal Tone select 0:Disable/1:Enable Interference resistant Valid keys:0 ~ 5 grade settings Keyboard mode... - Page 7 5.2 LED Indicator Definitions Indicator Status Description LED1 Light on Release the first/second lock Light on Register [Add Manage card] / Add user card Flash Register [Delete Manage card] / Delete user card LED2 Format or Configuration switching of DT-ACC and ID card, it waits for Double flash confirmation Light on...
- Page 8 Wrong password 10 times in a row, is locked Swipe invalid user card(When unlocking need swipe valid user card and password ) The access control is configured for the DT-ACC application The access control is configured for the ID card unlock application Register [Add Manage card] Register [Delete Manage card] Add user card...
-
Page 9: Set Unlock Time
5.4 Setting Steps LED1 LED2 LED3 Input the master code. Beep+, Beep (Default: [ ] +[#] ) (off) (off) (on) 1.Reset all settings 2.Set master code 3.Set digitron 4.Set unlock time display mode (Default: 1s) (Default 1234) Input the setting code. Input the setting code. -
Page 10: Set Unlock Mode
Input the master code. LED1 LED2 LED3 Beep+, Beep (Default: [ ] +[#]) (off) (off) (on) 5.Set unlock mode 6.Set touch key 7.Reset code setting 8. &# function setting prompt mode (Default 0(opened)) (Default Normal) Input the setting code. Input the setting code. Input the setting code. -
Page 11: Tone Select
Input the master code. LED1 LED2 LED3 Beep+, Beep (Default: [ ] +[#]) (off) (off) (on) 9. Tone select 10.Interference resistant 11.Keyboard mode 12.Unlock work mode grade setting (Default:1(scramble)) (Default:0) (Default 1(enable)) (Default 3) Input the setting code. Input the setting code. Input the setting code. -
Page 12: Device Address
Input the master code. LED1 LED2 LED3 Beep+, Beep (Default: [ ] +[#]) (off) (off) (on) 13. Backup(master / user 14.Update(master / user 15.Device address 16.RLC control card / password / tone) card / password / tone) (Default:0 ) (Default:0 ) Input the setting code. -
Page 13: Set The Code For User Group 1
Input the master code. LED1 LED2 LED3 Beep+, Beep (Default: [ ]+[#] ) (off) (off) (on) 17.Temporary(single use 18.Temporary(single use 19.Set the code for 20.Set the code for only) password for relay1 only) password for relay2 user group 1 user group 2 20~59 60~99 Input the setting code. -
Page 14: Register [Manage Card]
Input the master code. LED1 LED2 LED3 Beep+, Beep (Default: [ ]+[#] ) (off) (off) (on) 21.Register [Manage card] 22.Add user card 23.Delete user card 24.Format user card Input the setting code. Input the setting code. Input the setting code. Input the setting code. -
Page 15: Specifications
6.Unlock Operations Unlock by user code When the registered user code has been input using the keypad (1~12 digits), the digitron will display “OP1” or “OP2”, and the LED1 indicator lights up, and the system will synthesis sound of “Door is open”(If the Tone Select item is set to 1), then the electric door strike is unlocked.(note that you should press "#"... - Page 16 • Please clean the unit with soft cotton cloth, don't use the organic impregnant or chemical clean agent. If necessary, please use a little pure water or dilute soap water to clean the dust. • The unit is weather resistant. However do not spray high pressure water on access control keypad directly. Excessive moisture may cause problems with the unit.
