Page 1: User Manual
DT-TPC telephone converter User Manual Please read this manual carefully before using the product you purchase, and keep it well for future use.We reserve the right to modify the specification in this manual at any time without notice. - Page 2 About TPC Unit Discription: The TPC unit is a telephone converter designed for DT 2 wire system to divert calls from outdoor station to telephone or mobile phone.With TPC unit,you can communicate with outdoor person by your telephone or mobile phone which just like a remote control,you can do the operation of talking,unlock and so on.
- Page 3 Item Discription P201 • Main connection port • Power indicator(normally bright) LED1 • Signal indicator(flash) • Normal bright when activating divert function LED2 • Flash when the telephone number isn't preset • Normal bright when working in Debug mode (Debug mode:dialing sound can be heard from outdoor station) LED3 •...
-
Page 4: Din Rail Mounting
2. Mounting Direct Wall Mounting DIN Rail Mounting 109mm 3.DIP Switches Settings for TPC 3.1 SW401 switches settings: Setting Discription Bit1 the volume is twice louder than normal ( a d j u s t t h e v o l u m e o f t h e 2 3 4 the volume is normal telephone line) - Page 5 3.2 SW501 switches settings: Villa application: Total 6 bits for SW501 switches. Bit-6 must be set to OFF in villa system. Bit state Discription ON(1) OFF(0) Application for villa 1 2 3 4 5 To villa application,just Bit-1 is useful,Bit2 to Bit5 are invalid. Bit state Discription TPC just is a monitor that its user code is 15,besides,the...
- Page 6 Bit-1 to Bit-5 are used to set user code. The value is from 0 to 31, which have 32 different codes . When multi monitors are installed in one user, these monitors have to use the same User Code setting, and the Master/Slave mode should be set on the Monitor. Bit state User Bit state...
- Page 7 4.Telephone Number Setting on Monitor Touch screen monitors: • Maximum 3 telephone numbers can -Telephone Number- be set,touch the telephone number 1> _ 2> _ frame,then input the the number by 3> _ touching the digital keypad. Don’t divert calls Divert if not answered Divert simultaneously Exit&Unsave...
- Page 8 5.Operation Instructions Note: Divert function is activated in the following instructions Item Discription • Input 1# on your telephone or mobile phone to release the first lock Unlocking • Input 2# on you telephone or mobile phone to release the second lock •...
- Page 9 6.Wiring Basic in-out mode(for villa) CALL UNLOCK TALK/MON IN-USE 3 4 5 6 Code=14, DIP-6=off CALL UNLOCK TALK/MON IN-USE 3 4 5 6 Code=13, DIP-6=off CALL UNLOCK TALK/MON IN-USE 3 4 5 6 Code=0, DIP-6=off to telephone to telephone network IN OUT Bit1=off, DIP-6=off ID=00...
- Page 10 Star wiring mode(for villa) CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON 3 4 5 6 3 4 5 6 IN-USE IN-USE Code=14, DIP-6=on Code=13, DIP-6=on CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON 3 4 5 6 3 4 5 6 IN-USE IN-USE Code=11, DIP-6=on Code=12, DIP-6=on CALL...
- Page 11 Basic in-out mode(for apartment) CALL UNLOCK TALK/MON 3 4 5 6 IN-USE 3 4 5 6 Code=32, DIP-6=on Code=32, DIP-6=on to telephone network CALL UNLOCK TALK/MON IN-USE 3 4 5 6 Code=31, DIP-6=off 3 4 5 6 Code=31, DIP-6=on to telephone network CALL UNLOCK TALK/MON...
-
Page 12: Specification
Basic star wiring mode(for apartment) 3 4 5 6 3 4 5 6 Code=32, DIP-6=on Code=31, DIP-6=on CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON IN-USE IN-USE 3 4 5 6 3 4 5 6 Code=31, DIP-6=on Code=32, DIP-6=on CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON...
