Summary of Contents for Bennett Read OUTDOOR MISTING FAN
- Page 1 OUTDOOR MISTING FAN M O D E R N E F F E C T I V E C O O L I N G USER MANUAL YTS-40-A...
-
Page 3: Congratulations On Your Purchase
Thank you for purchasing a BENNETT READ OUTDOOR MISTING FAN. Your BENNETTT READ OUTDOOR MISTING FAN incorporates the latest technological advances and imitates the most powerful forces of nature in a sleek, elegant design to ensure that your home is effectively cooled. - Page 4 WARNINGS When using electrical appliances, in • Do not insert or allow foreign objects to order to reduce the risk of fire, electric enter any ventilation or exhaust opening shock and/or injury, these basic safety precau- as this may cause an electric shock, fire or tions should always be followed: could damage the unit •...
-
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Mist Outlet Cover 11. Upper Power Cable 2. Front Grille 12. Upper Power Cable Protective Cover 3. Mist Outlet Cover Screws 13. Stem 4. Fan Blade Screw 14. Lower Power Cable Cover 5. Grille Clamp 15. Water Tank 6. - Page 6 ASSEMBLY INSTRUCTIONS STEP 1: STEP 5: Insert Stem into Mist Generator Body and fas- Attach Misting Outlet Cover to Front Grille with the 4 x supplied screws. ten with size19 lock screw. Do not over-tight- en the lock screw. STEP 2: STEP 6: Remove Lower Power Cable Cover and attach Loosen the Grille Clamp to its widest.
-
Page 7: Turning On The Fan
STEP 8: STEP 11: Remove Upper Power Cable Cover and attach Fasten Mist Tube to Mist Generator Body and cable. Match correct cable colours (blue+blue the Mist Outlet Cover. and brown+brown). Place Upper Power Cable Cover back into position. TURNING ON THE FAN •... -
Page 8: Care And Cleaning
USING THE COOL MIST FUNCTION The Cool Mist function may only be used with the fan blades in operation. Before using the Cool Mist function check that there is sufficient water in the Water Tank. Turn the fan blades on first. Then turn on the misting function. When the water runs out, the self-protect mechanism engages and the mist generator will switch off. - Page 9 CONSUMER GUARANTEE The Bennet Read Outdoor Misting Fan has a 12 month product guarantee from Tevo (PTY) ltd. Tevo will replace or repair, at Tevo’s option, any defective or malfunctioning part due to manufacturing defect, free of charge from the date of purchase by the original purchaser for 12 months.
