Summary of Contents for ZIEHL-ABEGG Z-G-1NE
- Page 1 NETcon Z-G-1NE Part.-No. 380097, 380105 MODBUS-REPEATER Operating Instructions L-BAL-E244-GB 1732 Index 003 Part.-No.
-
Page 2: Table Of Contents
Operating Instructions NETcon Z-G-1NE Content General notes .......... - Page 3 Operating Instructions NETcon Z-G-1NE Delayed data transmission ......Enclosure ..........
-
Page 4: General Notes
We do not accept any liability for possible errors or omissions in the information con- tained in data, illustrations or drawings provided. ZIEHL-ABEGG SE is not liable for damage due to misuse, incorrect use, improper use or as a consequence of unauthorized repairs or modifications. -
Page 5: Safety Instructions
Operating Instructions NETcon Z-G-1NE Safety instructions 2 Safety instructions This chapter contains instructions to prevent personal injury and property damage. These instructions do not lay claim to completeness. In case of questions and problems, please consult our company technicians. 2.1 Intended use The equipment is to be used solely for the purposes specified and confirmed in the... -
Page 6: Requirements Placed On The Personnel / Due Diligence
Operating Instructions NETcon Z-G-1NE Safety instructions 2.4 Requirements placed on the personnel / due diligence Persons entrusted with the planning, installation, commissioning and maintenance and servicing in connection with the frequency inverter must have the corresponding qual- ifications and skills for these jobs. -
Page 7: Modifications / Interventions In The Device
ZIEHL-ABEGG.These parts were specifically designed for the device. There is no guarantee that parts from non-original sources are designed and manufactured in correspondence with load and safety requirements. Parts and optional equipment not supplied by ZIEHL-ABEGG are not approved by ZIEHL-ABEGG for use. 2.8 Operator’s obligation of diligence •... -
Page 8: Product Overview
The device is a MODBUS amplifier with complete galvanic separation, including auto- addressing of the Slaves. Information • Only this MODBUS REPEATER type Z-G-1NE can conduct the necessary signal for automatic addressing of ECblue fans (auto-addressing)! • The technical information document concerning ‘Automatic addressing for ECblue fans with MODBUS-RTU’... -
Page 9: Mounting
Operating Instructions NETcon Z-G-1NE Mounting 4 Mounting 4.1 General notes Attention! The following points must be complied with during the mechanical installation to avoid causing a defect in the device due to assembly errors or environmental influences: • Before installation remove the device from the packing and check for any possible shipping damage! Start-up is not allowed in the case of transport damage! •... -
Page 10: Voltage Supply
Operating Instructions NETcon Z-G-1NE Electrical installation Information The respective connections are represented in the enclosure of this manual ( Connection diagram)! 5.2 Voltage supply The supply voltage connection ( technical data) is implemented at the terminals “V+in” and “V-in” (regardless of polarity). -
Page 11: Front View And Connection
Operating Instructions NETcon Z-G-1NE Electrical installation 5.3 Front view and connection Version with MODBUS connection via RJ45 Version with MODBUS connection via termi- connector nals Part no.: 380097 Part no.: 380105 Connection Voltage supply 24 V DC input MODBUS Interface configured as Slave terminating resistor 150 Ω... -
Page 12: Communication
Operating Instructions NETcon Z-G-1NE Communication Attention! It is not permitted to connect the connections for automatic addressing (ID1 and ID2) to the PE conductor or to a voltage potential! The MODBUS input and MODBUS output interfaces are not identical; please pay attention to the proper connection (see connection diagram). -
Page 13: Limit Data Buffer
Operating Instructions NETcon Z-G-1NE Communication 6.2 Limit data buffer The device has a data buffer of 512 bytes, meaning that the REPEATER can transmit a maximum frame size of 512 bytes. Bytes exceeding this limit will not be transmitted! Information In the case of the currently available devices with which this REPEATER can be combined, the limit will not be exceeded. -
Page 14: Enclosure
Operating Instructions NETcon Z-G-1NE Enclosure 7 Enclosure 7.1 Technical data Voltage supply 24 V DC +/- 4 V (Phoenix 2-pin) Max. current consumption ca. 35 mA • input MODBUS RTU RS485 (Slave) Interfaces – Integrated terminating resistance of 150 Ω... -
Page 15: Connection Diagram
Operating Instructions NETcon Z-G-1NE Enclosure 7.2 Connection diagram L-BAL-E244-GB 1732 Index 003 Part.-No. 15/17... -
Page 16: Dimensions [Mm]
Operating Instructions NETcon Z-G-1NE Enclosure 7.3 Dimensions [mm] L-BAL-E244-GB 1732 Index 003 Part.-No. 16/17... -
Page 17: Manufacturer Reference
Operating Instructions NETcon Z-G-1NE Enclosure 7.4 Manufacturer reference Our products are manufactured in accordance with the relevant international regulations. If you have any questions concerning the use of our products or plan special uses, please contact: ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau...
