International Refrigeration Products, Inc.
MINI-SPLIT INSTALLATION
AND MAINTENANCE MANUAL
9H47YIMI
12H47YIMI
12H47ZIMI
18H47ZIMI
24H46ZIMI
30H48ZIMI
36H46ZIMI
950-0245revC
HEAT PUMP
9H47YOMI
12H47YOMI
12H47ZOMI
18H47ZOMI
24H46ZOMI
30H48ZOMI
36H46ZOMI
January 5, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9H47YOMI and is the answer not in the manual?

Questions and answers

Craig Nelson
May 23, 2025

Looking got part number for control board for a head unit. Model 9H47YOMI

Summary of Contents for Thermal Zone 9H47YOMI

  • Page 1 International Refrigeration Products, Inc. MINI-SPLIT INSTALLATION AND MAINTENANCE MANUAL HEAT PUMP 9H47YIMI 9H47YOMI 12H47YIMI 12H47YOMI 12H47ZIMI 12H47ZOMI 18H47ZIMI 18H47ZOMI 24H46ZIMI 24H46ZOMI 30H48ZIMI 30H48ZOMI 36H46ZIMI 36H46ZOMI 950-0245revC January 5, 2017...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS NOTE TO INSTALLER ........................2 INSTALLER SUPPLIED ITEMS ..................... 3 PARTS INCLUDED WITH UNIT ..................... 3 ITEMS FOR CONSIDERATION ..................... 3 UNIT INSTALLATION ........................5 Indoor installation ........................6 Outdoor Installation ........................9 Main Power Wiring ........................11 Controls Wiring ........................
  • Page 3: Note To Installer

    Installation and Maintenance Manual Report shipping damage to carrier IMMEDIATELY. Check units and box exterior for damage. NOTE TO INSTALLER This manual is to aid the qualified HVAC contractor in the installation and maintenance of this mini-split system. Please read and understand these instructions prior to installing the unit, failure to comply with these instructions may result in improper installation, operation and maintenance, possibly resulting in fire, electrical shock, property damage, personal injury or death.
  • Page 4: Installer Supplied Items

    INSTALLER SUPPLIED ITEMS The following items are necessary for the installation of the ductless mini splits.  Refrigerant line set: Flared connection only, suitable for R410A with both lines insulated, max length for connection see page 4 or specification pages 17 to 19. ...
  • Page 5 Installation (CONT’D). Unit Max Line Set Run Max Vertical Lift Line Sizes 1/4” Liquid – 3/8” Suction 9H47YMI 82 Feet 33 Feet 12H47YMI 1/4” Liquid – 1/2” Suction 82 Feet 33 Feet 12H47ZMI 1/4” Liquid – 1/2” Suction 18H47ZMI 98 Feet 66 Feet 3/8”...
  • Page 6: Unit Installation

    Installation (CONT’D). Wall Bracket: Mounting the outdoor unit on the wall is common; this allows mounting the outdoor unit closer to the indoor unit and also for a convenient installation. We offer wall brackets (Our Catalog# BR-440L for up to 440 lbs) as an accessory. UNIT INSTALLATION CAUTION! Follow Instructions, failure to follow instructions may cause possible malfunction and void any warranty.
  • Page 7: Indoor Installation

    Step 1 Indoor installation Remove Indoor and Outdoor units from the carton. Indoor unit carton contains Remote Control and Batteries, ensure these are kept in a safe place during installation. Step 2 Locate area to Install Indoor unit Indoor unit must be located a minimum of 4 ft. from the floor and 6” from the ceiling.
  • Page 8 Installation (CONT’D). For models: 30H48ZIMI, 36H46ZIMI 1 5 .3 " 1 0 .1 " 6 .8 " 1 3 .0 7 " Indoor U nit Outline 2 .0 5 " 2 .0 5 " L e ft re a r w a l l R i g h t re a r w a l l h o l e 2 .5 "...
  • Page 9 Installation (CONT’D) Step 5 Prepare Unit Line Set Connections Rotate refrigerant line stubs set gently through 90° (if mounting on an outside wall). For other line set configurations align the stubs as required. Condensate Hose Hose connection is sized to accept a 5/8'' OD or 1/2'' ID clear plastic hose to then extend to building drain. Connect it to the gray condensate line coming from the indoor unit.
  • Page 10: Outdoor Installation

    Installation (CONT’D). Step 6 Install unit on mounting bracket. Feed the line set stubs/condensate hose/wiring connections through the 3'' hole. Installation can be made easier by lifting the indoor unit and inserting a cushioning material (spacer) between indoor unit and the wall. Hook the top of the indoor unit to the top of the bracket (2 or 3 places) and once hooked, gently let it swing down and then push the lower portion of the indoor unit against the bracket until it snaps into the bracket.
  • Page 11 Installation (CONT’D). Step 8 Install drain joint Heat pump units require a drain joint. Before bolting the outdoor unit in place, you must install the drain joint at the bottom of the unit. Note that there are two different types of drain joints depending on the type of outdoor unit. ●...
  • Page 12: Main Power Wiring

    Installation (CONT’D). If a flared section is defective, cut it off and follow standard flaring procedures again. See caution note page 4. Align the center of the piping flare to its’ mating connector, then screw on the flare nut by hand and then tighten the nut with a spanner and torque wrench. Note: Exceeding the tightening torque will damage the flare surface.
  • Page 13: Wiring Diagram

    Installation (CONT’D). Control wiring from the outdoor unit must be a point to point; i.e. the terminal that the wire is attached to on the outdoor unit must be the same terminal it is wired to in on the Indoor unit. *** DO NOT CROSS WIRES BETWEEN TERMINALS.
  • Page 14: Refrigerant Charge

    REFRIGERANT CHARGE NOTE: Outdoor unit is pre-charged with enough R410A refrigerant for a line set up to 25 ft. long. For longer line set lengths additional charge must be WEIGHED in per the following table. Chart shows amount of additional refrigerant needed with different length line sets. Unit oz/ft 30ft...
  • Page 15 Before start up, double check all wiring has been properly connected. Review remote control functions in the Operators manual. Note: 1. A wall control is optional WCM1 (244-0001). For the details of installation and operation, please refer to the manual to be placed with the wall control. 2.
  • Page 16: Pressure Curves

    PRESSURE CURVES NOTE: After installation, the pressure reading should be as indicated below. Take from the service port, the pressure under the outdoor temperature should match the charts readings. Cooling Chart ° F ° C (23.89) (29.44) (35) (40.56) (46.11) 10.1 70/59 75/63...
  • Page 17: Heating Chart

    Heating Chart ° F 57/53 47/43 37/33 27/23 17/13 ° C (13.89/11.67) (8.33/6.11) (2.78/0.56) (-2.78/-5) (-8.33/-10.56) 30.3 28.5 25.3 22.8 20.8 32.5 30.0 26.6 25.4 23.3 33.8 31.5 27.8 26.3 24.9 ° F 57/53 47/43 37/33 27/23 17/13 ° C (13.89/11.67) (8.33/6.11) (2.78/0.56)
  • Page 18: Technical Specifications

    TECHNICAL SPECIFICATIONS 9,000 and 12,000 BTU Units (115V) 244-1401-E, 244-1401-C 244-1402-E, 244-1402-C (Thermal Zone - Sea Breeze) Indoor / Outdoor 9H47YIMI, 9H47YOMI 12H47YIMI, 12H47YOMI AHRI Reference Number 8752724 8740680 POWER SUPPLY Ph-V-Hz 115V~ 60Hz ,1Ph 115V~ 60Hz ,1Ph MINIMUM CIRCUIT AMPACITY...
  • Page 19: 12,000, 18,000 & 24,000 Btu Units (208/230V)

    12,000, 18,000 & 24,000 BTU Units (208/230V) 244-1403-E, 244-1403-C 244-1404-E, 244-1404-C 244-1405-E, 244-1405-C (Thermal Zone - Sea Breeze) Indoor / Outdoor 12H47ZIMI, 12H47ZOMI 18H47ZIMI, 18H47ZOMI 24H46ZIMI, 24H46ZOMI AHRI Reference Number 8740681 8740682 8740683 POWER SUPPLY Ph-V-Hz 208-230V~60Hz ,1Ph 208-230V~60Hz ,1Ph...
  • Page 20: 30, 000 And 36,000 Btu Units (208/230V)

    30, 000 and 36,000 BTU Units (208/230V) 244-1406-E, 244-1406-C 244-1407-E, 244-1407-C (Thermal Zone - Sea Breeze) Indoor / Outdoor 30H48ZIMI, 30H48ZOMI 36H46ZIMI, 36H46ZOMI AHRI Reference Number 8740684 8740685 Power supply Ph-V-Hz 208-230V~60Hz ,1Ph 208-230V~60Hz ,1Ph MINIMUM CIRCUIT AMPACITY BREAKER SIZE...
  • Page 21: Troubleshooting

    TROUBLESHOOTING Indoor Unit Error Code Display Display LED STATUS Indoor unit EEPROM parameter error Indoor / outdoor units communication error Zero-crossing signal detection error Indoor fan speed has been out of control Indoor room temperature sensor T1 open circuit or short circuit Evaporator coil temperature sensor T2 open circuit or short circuit Refrigerant leakage detection Overload current protection...
  • Page 22: The Importance Of Deep Vacuum

    THE IMPORTANCE OF DEEP VACUUM The purpose of a vacuum pump is to remove moisture and air from an A/C-R system. Modern systems are built tighter and charges are more critical. That means these systems have a greater sensitivity to moisture and other contaminants, making thorough evacuation more important than ever before.
  • Page 23: Warranty

    WARRANTY International Refrigeration Products warrants the accompanying split air conditioner or heat pump system to be free of defects in material and workmanship for the applications specified in the operation manual and installation manual for a period of one (1) year on parts and five (5) years on compressor, valid from the date of original retail purchase in the United States or Canada.
