User Manual
For Wireless Access Point WAP-348x
STATEMENT
General Statement
All the contents of this document are protected by law, without permitted by ROSIM,
any organization or individual should not copy or transmit this document in any way.
We've tried our best to make this specification accurate, but mistakes are still
unavoidable. The contents of this document are being checked periodically, your
suggestion will be appreciated.
The contents of this specification are accordant to the corresponding products.
Please keep attention to our website
www.rosimits.com
for any updating information,
which may not be informed of you in advance.
To make sure operation correctly, please read this user manual carefully before
installing. We are not responsible for any problems or damage caused by incorrect
operation.
Operation specifications issued by traffic department or related authorities should be
followed when installing, for example place traffic barriers and traffic indicator
correctly, operators wear special cloth, etc. We are not responsible for the personal
security of products installation.
ROSIM reserves all the rights of final interpretation.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAP-348 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Rosim WAP-348 Series

  • Page 1 STATEMENT General Statement All the contents of this document are protected by law, without permitted by ROSIM, any organization or individual should not copy or transmit this document in any way. We’ve tried our best to make this specification accurate, but mistakes are still unavoidable.
  • Page 2 User Manual: Wireless Access Point FCC Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3: Table Of Contents

    User Manual: Wireless Access Point CONTENTS Introduction ..........................4 Dimension ..........................4 Application ..........................4 Operation panel ........................5 4.1. Front panel ........................5 4.2. Rear panel ......................... 7 Functions ..........................10 5.1. Information collection ..................... 10 5.2. Network manager ......................10 5.3.
  • Page 4: Introduction

    2. Dimension 3. Application ROSIM provides various types of WAP products that can be used in many kinds of traffic systems like signal light optimization, traffic flow monitoring, travel information guidance and red light and speed enforcement, etc. Please select the suitable model before order.
  • Page 5: Operation Panel

    User Manual: Wireless Access Point 4. Operation panel This WAP-348X has front panel and rear panel. Front panel is used for operation, status indication, system configure and upgrade. Rear panel is used for communication, signal output and power supply interface. 4.1.
  • Page 6 User Manual: Wireless Access Point 2) Configure input WAP-348X has 4 toggle switches on the front panel. These are used to select operation model. Bit of switch Description BOOT_0 Use for factory debug. Keep it to “ON” position. BOOT_1 Use for factory debug. Keep it to “ON” position. TEST_SEL Test mode selection.
  • Page 7: Rear Panel

    User Manual: Wireless Access Point 7) SIM card slot This is only for WAP-348X with GPRS function; there is a SIM card slot in the front panel. Before using GPRS communication, a valid SIM card should be inserted in this slot.
  • Page 8 User Manual: Wireless Access Point 4) LAN (PoE) WAP-348x provides a 10/100 Mbps Base Ethernet port with optional PoE 802.3af/at available. Through the LAN port, WAP-348x can be connected to the TCP/IP network for data transmission as well as powered through Ethernet cable, which makes it very easy to use.
  • Page 9 User Manual: Wireless Access Point Detection Terminal (OC) status status status LOGIC_SEL=ON LOGIC_SEL=OFF Vehicle detected Connect Disconnect No vehicle Green Disconnect Connect WVD Warning Green flash Disconnect Disconnect WVD off line Disconnect Disconnect These terminals can output signal to other devices for controlling, for example traffic light optimization system, or camera trigger signal.
  • Page 10: Functions

    User Manual: Wireless Access Point 7) Net antenna Net antenna interface is used to connect with an external antenna. WAP-348X uses this antenna to communication with all the WVD sensors that are installed in the application site. 5. Functions 5.1. Information collection WAP-348X collects all the information detected by WVDs installed on each lane of the road.
  • Page 11: Detection Indication

    User Manual: Wireless Access Point 5.4. Detection indication WAP-348X has 48 LEDs which are corresponding to 48 WVDs. The status of these each LED indicates the status of corresponding WVD. 5.5. Detection result output There are 48 output terminals in the rear panel of WAP-348X. They are numbered from 1 to 48 and are corresponding to 48 detect channels and LEDs in the front panel respectively.
  • Page 12: Poe

    Storage temperature -40~85℃ 7. Accessories ROSIM provides two kinds of antenna for customers. The Yagi directional antenna is usually suitable for application site where the communication distance between WAP-348X and each sensor are long. While the whip antenna, which is an omnidirectional antenna, is usually suitable for those short range applications in which the distance between WAP-348X and sensors are no more than 30 meters.
  • Page 13: Configuration

    8. Configuration WAP-348X can be configured to run in real-time or period traffic flow monitoring mode, or speed measurement mode. ROSIM provides SensorManager as a configuration tool to customers as well as testing software. More details please see the user manual of SensorManager.
  • Page 14: Output Terminals

    User Manual: Wireless Access Point up the antenna. After the antenna was set up, please screw the RF cable to the connector on the back of antenna, and wrap it by waterproof tape. The length of the RF cable can be 10 meters or 20 meters, and also can be customized according to the requirement.
  • Page 15: Data Communication

    User Manual: Wireless Access Point Vehicle detected Connect Disconnect No vehicle Green Disconnect Connect WVD Warning Green flash Disconnect Disconnect WVD off line Disconnect Disconnect 9.5. Data communication WAP-348X provides a variety of data communication interface, such as RS-232 port, Ethernet port and USB port as well.
  • Page 16: Supports

    WVDs, and to confirm whether the installed WVDs are working regularly as well. 10. Supports ROSIM creates and manufactures high quality wireless parking detection devices. We provide customers 24 hours on-line supports. Rosim ITS Technology Co., Ltd. Tel: +86-760-85313186...
