Summary of Contents for Kaicom K7
- Page 1 Kaili Internet of Things Handheld Terminal K7 User Manual Hangzhou Kaili Communication Co., Ltd.
- Page 2 Abstract K7 is the first dual 4G full Network access intelligent wireless data acquisition terminal, with huge battery capacity and ultra-long standby time; the 800W HD camera, combined with 4-inch high-resolution and capacitive touch screen, fits Android system operating habits; the ultra-thin body gives very comfortable operation experience.
- Page 3 3) Every move of package can be recorded with PDA, it is simple and precise to track the status of goods. 3. Delivery service 1) When goods go out of warehouse, Kaicom PDA will be used to scan each package and change the status. 2) PDA tranmit real-time data to synchronize information with platform and other department.
- Page 4 It restraints the communication when the doctor leaves office to check the sickness. It needs mobile products for data connection. Kaicom PDA can record history of each patient, help doctor to know well of the status. It not only provide efficient therapy, but also improve relationships between doctor and patient.
- Page 5 Hardware Earphone Scanning Button Scanning Button HOME Button Volume Button Talkback Button Scanning Button Return Key Menu Button Right Soft Button Left Soft Button Delete Button Fn Shortcut Button Caps Lock Button Lock Screen Button Power Button Enter Button Numbers, letters and strokes keypad Camera Window Battery Cover Lock Straps Supporter...
- Page 6 The Correct Reading Approaches The Wrong Reading Approaches...
- Page 7 Technology specification Product Processor MTK6735 Quad-core*1GHz Extensive SD card 4-inch（WVGA，Resolution：480*800 ） General Display capacitive screen Camera(optional) 8M pixel, automatic focus, flash is available Audio Mic Speaker 3.5mm earphone/reciever Android 5.1 Supports GPS,GALILEO,GLONASS and BEIDOU Resolution：0.127mm； Readable Distance：50-300mm； Scanning frequency：100± 20/s； Scanning 1D Scanning engine Engine...
- Page 8 FDD-LTE(B1,B3) TD-LTE(B38,B39,B40,B41) TD-SCDMA(B34,B39) CDMA EV-DO Rev.A(BC0) UMTS/HSPA+/DC-HSDPA(B1,B8) GSM/EDGE(850,900,1800,1900) Network WLAN 802.11a/b/g/n, 2.4G 802.11n，5.8G Bluetooth V2.1+EDR, V3.0+HS and V4.1 HS compliant HF 13.56MHz，Readable distance：2-5cm ISO14443A/B,ISO15693 Battery 3.7V 4000mAH Consumption <2W Power supply Standby time >100 hour Power Input：110-240V AC，50/60Hz，output：5.0V DC Safe certificate CCC CE ROHS Certification Protection certificate...
- Page 9 Meanwhile, we provide accessories in order to reinforce users’ experiences. Excellent data management and control Equipped with advanced scanning engine, K7 can recognize data with the modes of 1D, 2D and NFC. Even in severe application scene like rainy, misty, blurry or deficiency, it can still achieve efficient, accurate and batch data operation.
- Page 10 Notice! The battery of this product can only be charged with the specified charger. Use of other chargers may cause overheat, explosion and burning of the battery. If the product is hot or start to smoke or emit abnormal odor, the user should immediately cut off the power supply, unplug the power charger, remove the battery, and contact the after-sales service center of the company.
- Page 11 Please browse Kaili’s website or call the company for more information about Kaili’s products. Hangzhou Kaili Communication Co., Ltd. Address: 12F, Building B, Conba Tower, No. 288 Jiangnan Ave, Binjiang District, Hangzhou City Market: 0571-86081223 Fax: 0571-86983802 Website: www.kaicom.cn/en Alibaba: www.kaicomcn.en.alibaba.com...
