IntelliPEAK DirectLink WiFi
IntelliPEAK DirectLink Applications Guide
IntelliPEAK DirectLink can be installed to control the following loads.
Description
HVAC
Water Heater
Pool Pump
Refrigeration
It requires connection to line power and must be installed by a trained and experienced
technician.
Do not under any circumstances open the door and touch any components
inside, as line voltage (120 – 240 VAC) is present. You could damage this product or cause
a hazardous condition if you fail to follow these instructions.
Need Help? For assistance with this product, please visit http://www.comverge.com or call?
HVAC
For HVAC, IntelliPEAK DirectLink is typically installed outside, near your compressor. It is
wired to the same power source as the compressor and relays inside IntelliPEAK will
intelligently reduce the compressor run time during a control event to reduce the demand on the
electrical grid during event periods. Relay(s) inside the device will interrupt the control signal
from the thermostat to the compressor and will only disable the compressor periodically during a
control event. The indoor fan will continue to run during this time. The indoor temperature is
expected to rise a few degrees during the event, depending on the amount of insulation in the
premise.
Yes
Yes
Yes
Yes
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for IntelliPeak DirectLink WiFi
- Page 1 For HVAC, IntelliPEAK DirectLink is typically installed outside, near your compressor. It is wired to the same power source as the compressor and relays inside IntelliPEAK will intelligently reduce the compressor run time during a control event to reduce the demand on the electrical grid during event periods.
- Page 2 LED and What Do They Indicate IntelliPEAK contains up to four LED (Light Emitting Diodes) underneath a clear window in front of the unit. These LEDs show the operation of the IntelliPEAK device as shown below: Used by installer Shows status of...
- Page 3 LED will blink at different patterns as shown below: Link LED Status Client mode - no network connection Ad-hoc mode – IntelliPEAK is creating its 0.5 second blink own Wi-Fi network to allow entry of credentials...
- Page 4 • Water heater/pool pump/refrigeration – 0 seconds Hardware Error Reporting If the IntelliPEAK hardware senses an error that prevents normal operation of the switch, then all LED’s will flash as an indicator of this condition. If this happens repeatedly, then the switch should be replaced.
- Page 5 Please follow the steps below to reset the credentials stored in IntelliPEAK: 1. Note the serial number of IntelliPEAK. There should be a serial label on the side of the product. Note the last four digits of the serial number.
- Page 6 5. If the settings page does not appear after a few seconds, type “DirectLink/settings” in the address bar, then press ENTER. Use the pull-down on the settings page to select your user network name 7. If your wireless Internet router is set to hide the network name or your network is not listed in the pull-down, click on the link “Click Here If your WIFI network is not listed”...
- Page 7 8. Manually enter the WiFi Network Name (SSID), select the security type from the drop down menu, and enter the security key.
- Page 8 Enter the network password for your network in the Security Key field:...
- Page 9 10. Once all fields are filled in correctly, click on the Save button. 11. The settings page will now show an overview of the settings you entered. If all settings are correct, click on Apply. If you need to correct any settings, click on Cancel. 12.
- Page 10 Specifications 120VAC – 240VAC auto-ranging Power Input Power Consumption Less than 12 VA Operating Condition -35° to +85° C, 0% - 95% humidity (non- condensing) Regulatory FCC part 15; UL 916 Relay Rating/Cycles 2 Function (2F): 24VAC, 2 Amp 1 Function (1F): 240VAC, 30 Amp Resistive Electrical Endurance: 250,000 cycles at rated worst-case loads Mechanical Endurance: 10 million cycles at...
