SMOVE FBOX MINI User Manual

Photo booth
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
PHOTO BOOTH SMOVE FBOX MINI
www.smove.pl

Advertisement

loading
Need help?

Need help?

Do you have a question about the FBOX MINI and is the answer not in the manual?

Questions and answers

Summary of Contents for SMOVE FBOX MINI

  • Page 1 USER MANUAL PHOTO BOOTH SMOVE FBOX MINI www.smove.pl...
  • Page 2 User Manual 1. A standard set of Photo Booth SMOVE FBOX MINI Standard set contains: Photo booth shell,  Base plate  Stand / Leg  Printer shelf  Printer shell,  Canon EOS camera with a power supply adaptor, ...
  • Page 3 User Manual 2. Assembling of Photo Booth: 1. Put the Base plate on the workplace of the Photo booth. Prepare screws to bind the Stand with the Base plate (4x M6 with big head) p. 3...
  • Page 4 User Manual 2. Pull the Power supply cable (5m IEC C13) through the hole in the Base plate and then through the hole in the Stand. p. 4...
  • Page 5 User Manual 3. Screw down 4 screws to bind the Base plate with the Stand. Warning! Keep caution not to crush the cables! p. 5...
  • Page 6 User Manual 4. Plug the main power supply cable into the socket (cable) in the Stand. 5. Hide connected cables inside the Stand. IR sensor (red arrow) could be left outside the Stand. p. 6...
  • Page 7 User Manual 6. Put the Photo booth shell on the Stand/Leg by placing the guides (red arrow) inside the Stand p. 7...
  • Page 8 User Manual 7. After placing the Photo booth shell on the Stand/Leg – secure the connection by binding it by M6 screw p. 8...
  • Page 9 User Manual 8. Pull the Power supply cable (1m IEC C13-C14) and USB A-B cable (1m) through the hole in the Photo booth shell p. 9...
  • Page 10 User Manual 9. Tilt the Photo booth shell to the front, so it will be possible to connect cables to the Stand. 10. Plug the Power supply cable (1m IEC C13-C14) and USB A-B cable (1m) into the sockets inside the Stand/Leg. p.
  • Page 11 User Manual 11. Turn ON the Main Power Source by holding the button (red arrow) till you hear constant sound. 12. Screw the camera to the mounting, then place DC module inside the camera. p. 11...
  • Page 12 User Manual Warning! Please notice to close the battery door. If it will be opened, the camera will not turn ON. p. 12...
  • Page 13 User Manual 13. Connect the Camera to the Computer using Mini USB cable. p. 13...
  • Page 14 User Manual 14. If your Photo Booth is provided with Flash module – Plug in the hot shoe into the camera slot and connect it with Flash module using the cable (Jack-Synchro). 15. Turn on Flash module and adjust its strength by knob (if your booth is provided with it). p.
  • Page 15 User Manual 16. Photo booth has possibility to tilt camera from Vertical to Horizontal position (Portrait / Landscape). To rotate the camera – Loosen the screw (red arrow), then tilt the camera mounting and tighten the screw. p. 15...
  • Page 16 User Manual 17. Place the Printer shelf on the Stand/Leg. p. 16...
  • Page 17 User Manual 18. After placing the Shelft on the Stand – secure it by M6 screw. 19. Place the Printer shell on the center of Printer shelf. p. 17...
  • Page 18 User Manual 20. Bind the Printer shell with Printer shelf using M6 screws with small heads (red arrows). Then plug AC cable (built in Printer shell) to the Stand/Leg and connect Printer Shell with Stand by USB A-B (0,5 m) or USB B-B 21.
  • Page 19 User Manual 22. Turn the ring lamp on. There are 3 modes available: Off.  Control mode (the light intensity can be adjusted with the remote control or by switches on the dimmer panel).  Permanent mode (full light strength). ...

  • Page 20: Technical Handling

    User Manual 3. Technical handling Placing and replacing printing materials and supplies: https://youtu.be/wQDOzddzQCU To replace consumables it is necessary to open the Printer shell by using Service key and removing the Upper part. p. 20...
  • Page 21 User Manual Bulb exchanging Using the knob, unscrew a bolt securing a LED bulb you need to exchange, then replace with a new bulb (type: MR16 12V, max 5W, „pure white” light shade). p. 21...
  • Page 22 User Manual 4. Photo Booth software WARNING! install WINDOWS UPDATES and reduce other updates to a minimum, to avoid software conflicts with Photo Booth program. complete software manual English, covering pages, available here: http://www.breezesys.com/DSLRRemotePro/support.htm Key camera settings Once the camera is in M mode, you can set all the parameters using camera buttons.
  • Page 23 User Manual If a room where you are taking photos is relatively bright, we suggest to set AF lens mode. If the room is dark, or blinking lights or smoke might occur, choose MF mode. In MF lens mode you will adjust sharpness manually using a lens ring. p.
