Summary of Contents for Design SHIFT ORWL
- Page 1 ORWL User Guide Document USER GUIDE FOR ORWL CONFIGURATION Version 0.2 ...
-
Page 2: Table Of Contents
ORWL User Guide Document Introduction 4 Hardware Requirements 4 Configuration of ORWL 4 Step 1: Power on ORWL 4 Step 2: Display predefined pin entry message 5 Step 3: Press power button on the ORWL 6 Step 4: Enter predefined pin 6 Step 5: Predefined pin verification status 7 Step 6: Display user pin entry message 8 Step 7: Press power button on the ORWL 8 Step 8: Enter user pin 8 Step 9: Display user pin reentry message 9 Step 10: Press power button on the ORWL 9 Step 11: Confirm the user pin 9 Step 12: User pin configuration status 9 Step 13: Display hash verification message 10 Step 14: Display hash value 10 Step 15: Press power button on ORWL 11 ... - Page 3 ORWL User Guide Document Revision History Version Date Description of changes Author(s) 0.1 09-05-17 Initial draft on ORWL configuration user guide Chaitra Document modified based on the comments 0.2 13-06-17 Chaitra provided by Daniel ...
-
Page 4: Introduction
ORWL ● KeyFOB ● 3. Configuration of ORWL Following are the steps to configure the ORWL device. Step 1: Power on ORWL Power on the ORWL by pressing the button provided on ORWL. The position of button is shown in ... -
Page 5: Step 2: Display Predefined Pin Entry Message
ORWL User Guide Document Following the ORWL logo, “Enter your PIN” message is displayed. If custom pin is already set by user ... -
Page 6: Step 3: Press Power Button On The Orwl
ORWL User Guide Document Step 3: Press power button on the ORWL Followed by pin entry message, “Please press power button to proceed” message is displayed. Press power button on the ORWL to proceed with configuration. Step 4: Enter predefined pin Once power button is pressed, enter the 6-digit predefined PIN received through mail. ... -
Page 7: Step 5: Predefined Pin Verification Status
indicates the number of attempts remaining. If retry count of 10 is already tried, then a message “ORWL LOCKED !!!” will be displayed and the ... -
Page 8: Step 6: Display User Pin Entry Message
ORWL User Guide Document Step 6: Display user pin entry message Once PIN verification is successful, a message “Set your PIN” followed by PIN verification message is displayed. ... -
Page 9: Step 9: Display User Pin Reentry Message
ORWL User Guide Document Step 9: Display user PIN reentry message Once custom PIN entry is successful, a message “Re-enter PIN” is displayed. Step 10: Press power button on the ORWL This is same as step 3 to proceed with next step. Step 11: Confirm the user PIN Enter the same 6-digit PIN which is entered in step 8 to confirm the user PIN. The UI is the same as ... -
Page 10: Step 13: Display Hash Verification Message
mail. If hash is correct, user needs to press the power button on the ORWL and flow continues with ... -
Page 11: Step 15: Press Power Button On Orwl
ORWL User Guide Document Step 15: Press power button on ORWL User needs to press power button on ORWL to indicate proper hash verification and safe shipment of ORWL. A message “HASH CONFIRMED SAFE SHIPMENT” is displayed for three seconds. ... -
Page 12: Step 16: Display Pair Keyfob Message
ORWL User Guide Document Step 16: Display Pair Keyfob message A message “Pair Keyfob to associate” is displayed. Step 17: Present Keyfob to ORWL Present a keyfob to ORWL to proceed with the association process of keyfob with ORWL. ... -
Page 13: Step 18: Display Keyfob Association Status
ORWL User Guide Document Step 18: Display Keyfob association status On successful association, an association image is shown for ten seconds and flow continues with next step. If association does not happen in 120 sec, “Timeout Rebooting” message is displayed and ... -
Page 14: Step 19: Display Completion Of Configuration Status
ORWL User Guide Document Step 19: Display completion of configuration status On completion of ORWL configuration, message “ORWL configured Rebooting” is displayed. Now ORWL is configured and it is in user mode. 4. PIN verification steps after custom reboot Following are the steps to be followed for custom reboot only if the custom PIN is already set by the ... -
Page 15: Step 21: Press Power Button On The Orwl
ORWL User Guide Document Step 21: Press power button on the ORWL This is same as step 3 to proceed with next step. Step 22: Enter custom PIN Enter the 6-digit custom PIN which is configured by user to verify the user. The UI is same as figure ... - Page 16 ORWL User Guide Document If retry count of 10 is already tried, then a message “ORWL LOCKED !!!” will be displayed and the ...
