- Page 1 Wireless Stereo Headset Portable Stereo Transmitter Operating Instructions MX-BT30 / MX-TM3 ©2007 TOHO SUPPLY CO., LTD.
- Page 2 WARNING CAUTION The user is cautioned that changes and These operating instructions modifications made to the equipment include the important operating without the approval of manufacturer and handling precautions. Read could void the user’s authority to operate these instructions carefully to this equipment.
-
Page 3: What Is Bluetooth Technology
Welcome! Thank you for purchasing MAXFUN wireless stereo headset and transmitter. This unit uses BLUETOOTH wireless technology. Key Features • Universal compatibility with all BLUETOOTH enabled phones and music player • Faster Bluetooth version 2.0 for pairing and connection Improved call quality and lower power consumption. -
Page 4: Bluetooth Function
BLUETOOTH function Pairing BLUETOOTH devices need to be registered with each other beforehand. This registration is called “Pairing.” Once BLUETOOTH devices are paired, there is no need for pairing again. Wireless Stereo BLUETOOTH Headset mobile phone, etc. PAIRING PAIRING ➡ SEE PAGE 7 Listening to music Talking on the phone BLUETOOTH connection... -
Page 5: Location And Function Of Parts
Location and Function of Parts PLAY/PAUSE button MF (Multi function) button Indicator FF/REW button VOLUME button USB jack Microphone 1 PLAY/PAUSE button Switches between playing music and pause. 2 MF (Multi function) button Controls various call functions. Power ON/OFF 3 Indicator Indicates the power status of the unit. -
Page 6: Charging The Unit
Charging the Unit This unit contains a rechargeable Lithium-Ion battery which should be charged before using for the first time. 1. Connect the supplied USB cable to the unit and computer. Rechargeable battery lasts longer if it is charged about 4 hours the first time. To computer USB jack USB Cable (Supplied) -
Page 7: Pairing With Multiple Devices
3. Perform pairing procedure on the connecting device to detect this unit. The list of detected devices appears on the display of the connecting device. This unit is displayed as “MX-BT30.” If “MX-BT30” is not displayed, repeat from step 1. 4. Select “MX-BT30” on the display of the connecting device. -
Page 8: Wearing The Headset
Wearing the headset Note Do not pull out the neck cord forcibly. Hook the hanger section around the top of ear and ensure that it is covered by the ear pad. Wear the housing marked R in your right ear and the one marked L in your left ear. Make sure that you wear the headset firmly. -
Page 9: Listening To Music
Listening to music Check the following before operating the unit. 1. The BLUETOOTH device is turned on. 2. Pairing of this unit and the BLUETOOTH device is complete. 3. The BLUETOOTH device supports the A2DP. PLAY/PAUSE button MF button 1. Press and hold the MF button for about 3 seconds while the unit is FF/REW button turned off. -
Page 10: To Receive A Call
Calling Check the following before operating the unit. 1. The BLUETOOTH function is active on the mobile phone. 2. Pairing of this unit and the BLUETOOTH mobile phone is complete. PLAY/PAUSE button MF button FF/REW button VOLUME button 1. Press and hold the MF button for about 3 seconds while the unit is turned off. -
Page 11: Calling While Playing Back Music
TO ADJUST THE VOLUME 1. Press the Volume +/- button while calling. You cannot adjust the volume when not communicating. Volume level for calling and listening to music can be set independently. TO STOP USE 1. Terminate BLUETOOTH connection by the BLUETOOTH mobile phone. 2. -
Page 12: Troubleshooting
Troubleshooting If you run into any problems using this unit, use the following checklist. Should any problem persist, Contact the place of purchase or “Customer Support Center.” The unit is not turned on ➡ Battery of the unit might be low. Charge the battery of the unit. Cannot charge the battery ➡... - Page 13 Welcome! Thank you for purchasing MAXFUN Portable Stereo Transmitter. This unit uses BLUETOOTH wireless technology. • You can enjoy wireless music from your BLUETOOTH device (i.e., headset) capable of transmitting audio signal by connecting this unit to any portable music player, audio equipment or computer with a 3.5 mm plug.
- Page 14 Location and Function of Parts MF (Multi function) button Indicator 1/8 (3.5 mm) plug USB jack 1 MF (Multi function) button Controls various functions. 2 Indicator Indicates the power status of the unit. 3 USB jack Use for USB cable for charging. 4 1/8 (3.5 mm) plug Use for connecting to audio device.
- Page 15 Charging the Unit This unit contains a rechargeable Lithium-Ion battery which should be charged before using for the first time. 1. Connect the supplied USB cable to the unit and computer. Rechargeable battery lasts longer if it is charged about 4 hours the first time. To computer USB jack USB Cable (Supplied)
- Page 16 Pairing What is pairing? BLUETOOTH devices need to be registered with each other beforehand. This registration is called “Pairing.” Once BLUETOOTH devices are paired, there is no need for pairing again, except in the following cases. • When paring information is deleted after repair, etc. •...
- Page 17 Listening to music Check the following before operating the unit. 1. The BLUETOOTH device is turned on. 2. Pairing of this unit and the BLUETOOTH device is complete. 3. The BLUETOOTH device supports the A2DP. MF (Multi function) button Indicator 1.
- Page 18 Troubleshooting If you run into any problems using this unit, use the following checklist. Should any problem persist, contact the place of purchase or “Customer Support Center.” The unit is not turned on ➡ Battery of the unit might be low. Charge the battery of the unit. Cannot charge the battery ➡...
- Page 19 Precautions On BLUETOOTH communication • BLUETOOTH wireless technology operates within a range of about 10 meters (about 30 feet). Maximum communication range may vary depending on obstacles (metal, wall, etc.) or electromagnetic environment. • The antenna of this unit is built into the housing for the right ear. The sensitivity of BLUETOOTH communication will improve by placing a connected BLUETOOTH device on your right side.
-
Page 20: Specification
Specification Wireless Stereo Headset MX-BT30 Portable Stereo Transmitter MX-TM3 General General Communication System Communication System BLUETOOTH Specification version 2.0 BLUETOOTH Specification version 2.0 Output Output BLUETOOTH Specification Power Class 2 BLUETOOTH Specification Power Class 2 Maximum communication range Maximum communication range... - Page 21 This warranty covers any defects or malfunctions in your new MX-BT30 / MX-TM3. How long does the coverage last? This warranty lasts for one year from the date you purchase your MX-BT30 / MX-TM3. (Coverage terminates if you sell or otherwise transfer the MX-BT30 / MX-TM3) What will MAXFUN do? MAXFUN will repair or replace any defective or malfunctioning part at no charge.
