GlacialTech GL-FL55 Series User Manual

GL-FL55 Series
Thank you for choosing the GL-FL55 Series LED products.
Please install and use the products according to the following directions to ensure normal
function and operation.
Please use stainless screw to fix holder and make sure screwed tightly.
Please do not add/remove any electrical components to/from the products or
change/tamper the original electrical design without our permission.
Please do not add/remove any mechanical components to/from the products or
change/tamper the original mechanical design without our permission.
If you do not follow these instructions to properly install and use the GL-FL55 Series, you
will not be eligible for warranty compensation or protection.
We do not take any responsibility for product damage resulting from improper installation
or abnormal usage.
Installation Steps
Step 1.
Before installation, please turn off
the power switch.
GL-FL55 Outlook
246
120
42.5
©2015 GlacialTech Inc. All rights reserved. All brand names and trademarks are the properties of their respective owners.
The specifications are subject to change without notice.
For further information please visit official website : www.GlacialLight.com
The set up process should be executed by qualified (Certified) engineers.
Step 2.
Connect the fixture's power cables to their
corresponding colors of the power source
and entwine together. Connect the
grounding line to the grounding screw of
the grounding devices.
(L) Brown or Black
(N) Blue or White
Green and Yellow
Grounding line should be fixed
perpetually and not allow to disconnect.
220
Net Weight:
3 Kg(with driver & lampshade)
Step 3.
Screw the LED fixture tight onto a
wall or a stand and adjust the
angle in accordance with
individual needs.
* Please use stainless screw
to fix holder and make sure
screwed tighly.
Notices
138
1. Avoding improper use to exceed the criterion
limitation of lamp operation temperature.
2. Allow lamp to cool before replacing.
3.
Not suitable for dimming function.
1. If the external flexible cable or cord of this
luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service
agent or a similar qualified person in order
to avoid a hazard.
2. Prior to installation, remove the AC power.
0 ~ 180°
(20° / Grid)
CAUTIONS
IP66
17-FL55S000001
