Summary of Contents for 4G WGHK22009
-
Page 1: Quick Start Guide
QUICK START GUIDE Model: WGHK22009 Dear Users: Thank you for buying our product. This is an User’s Guide, in order to make sure you can use it conveniently, please read it before you use the product. -
Page 2: Appearance And Buttons
1. Appearance And Buttons Description of Button Functions Micro USB Port Earphone jack Telephone Receiver Front Camera Power on/off Volume +/- Rear Camera Flash Light TF Card Slot SIM Card Slot 2 SIM Card Slot 1 Speaker... -
Page 3: Main Function
2. Specifications SPECIFICATIONS Processor MTK 8735 Quad-Core Cortex A53 1.3Ghz Android 5.1 8” IPS screen, Resolution 800*1280, 5 points capacitive screen Display Storage WIFI Support Camera 2.0MP front camera, 5.0MP rear camera with flash light Support Bluetooth Support Support 2G/3G GSM 850/1900MHz WCDMA 1900/850 FDD-LTE:/B4/B12/B17 G-Sensor Support... -
Page 4: Function Definition
4. Function Definition 1. “ ”：Power Key, On shutdown state ,long press the power key and the system will enter the process of Startup，on boot state，long press the power key and the system will come out for the turn off information; on boot state，short press will lock the interface. 2.“Volume +/-”: Press to volume increase or decrease . - Page 5 6.2. Shutdown Long press the power key then pop-up options will be on the desktop, choose the option of Power off , Tap OK to shutdown.
-
Page 6: Main Menu Operation
7. Main Menu Operation Slide the screen, you can see the interface with many applications as shown below: First slide the icon to unlock the interface. Then you can see the main interface as shown below:... -
Page 7: Network Connection Methods
In this interface, you can set the system, operate the existed application, install a new application, and start touch calibration, play music and video, browse webpage, play game and other operations by the applications on it. 8. Network connection methods: 8.1. -
Page 8: Treatment For Common Problems
8.3. External 3G network Use OTG cable to connect external equipment.It will have a 3G signal under the lower- right corner. 8.4. Mobile Networks If you have insert SIM card tablet pc , you could use the mobile networks by 2G/3G data connection. -
Page 9: Fcc Rf Exposure Information
The description of APN： 1.APN (Access Point Name),mean the name of network operator in local place ,for example,Etisalat stands for the mobile network operator in UAE. 2.MCC stands for Code of network operator .The code is made of three numbers which could identify which country the users are in .For example,460 is stands for China and 424 for UAE. -
Page 10: Normal Position
Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder. RF Exposure Information: This product is compliance to FCC RF Exposure requirements and refers to website https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm search for FCC ID: 2ADCR-WGHK22009 to gain further information include... - Page 11 SAR Values. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
