Virtual industries SMD-VAC-HP Operating Instructions And Specification

Specifications

ESD SAFE:
GROUNDED THROUGH THREE WIRE CORD
ELECTRICALLY CONDUCTIVE VACUUM CUPS
STATIC DISSAPATIVE RUBBER HOSE
STATIC DISSAPATIVE PLASTIC NOZZLE
VACUUM:
MINIMUM 15 INCHES OF MERCURY AT SEA LEVEL.
DIMENSIONS:
LENGTH HEIGHT
2.8" (71mm) 6" (152.4mm)
WEIGHT:
24 OUNCES (650 GRAMS)
POWER REQUIREMENTS:
MODEL # V8100A 110 VOLTS A.C.
MODEL # V8100A-220 220 VOLTS A.C.
SMD-VAC™-HP OPTIONS
VACUUM INTERRUPTER P/N V3025
Facilitates precision placement of small parts. The hand that holds the wand is used to
position and/or rotate the part being placed while the other hand makes or breaks the
vacuum.
SELECTION OF VACUUM CUPS WITH PROBES
The vacuum cups are a soft rubber material that allow handling a wide variety of small
parts.
SELECTION OF MINIATURE VACUUM TIPS
These tips are designed to handle tiny parts as small as 0.01" (0.25mm).
OPTIONAL FOOT SWITCH P/N VFS-1
Facilitates precision placement of small parts. The hand that holds the wand is used to
position and/or rotate the part being placed while the foot switch makes or breaks the
vacuum.
OPTIONAL HAND SWITCH P/N VHS-1
Facilitates precision placement of small parts. The hand that holds the wand is used to
position and/or rotate the part being placed while the other hand makes or breaks the
vacuum.
Virtual Industries, Inc.
2130 Victor Place
Colorado Springs, CO 80915
U.S.A.
For technical assistance call toll free 1-800-590-2829
Tele: 719-572-5566
Fax: 719-572-5504
8:00 A.M. to 4:30 P.M. Mountain Standard Time
WIDTH
4" (101.6mm)
60 HERTZ 8 WATTS
50 HERTZ 8 WATTS
OPERATING INSTRUCTIONS AND SPECIFICATIONS
SMD VAC™ HP
ESD Safe Vacuum Handling Tool
9/26/08
Model No. V8100A
Model No. V8100A-220
