Summary of Contents for PROSPACE HUB 2.0
- Page 1 User Manual Model: HUB 2.0 PROSPACE PTE LTD...
- Page 2 Hub 2.0 Manufactured by: ProSpace Pte Ltd. Descriptions: The hub is used to receive RF 433Mhz signals sent by other separate PIR sensors/devices – and thereafter transmit the data to 3G network via embedded 3G module (with 3G simcards) Primary function Receive RF 433 Mhz signals Transmit data to Internet via 3G network Environment To be deployed in sheltered environment not exposed to rains and direct sunlight. (eg- home, offices) Power rating DC 5V, 2.5A Dimension 87mm x 58mm x 23mm User manual – How to deploy: 1. Power-on the hub2.0 by connecting it’s adapter to normal power socket readily available in any buildings. 2. The hub2.0 will then start collecting/receiving signals from nearby PIR devices.
- Page 3 3. To read the RF data collected, below the 3 ways: a. Connect the hub2.0 with a monitor/laptop via HDMI port. b. Connect LAN cable to hub2.0 to transfer data to Internet. c. To transfer data wirelessly, insert 3G simcard into the hub2.0 and connect to mobile broadband/3G network.
- Page 4 Use the HUB in the environment with the temperature between-10℃ and 40℃, otherwise, it may damage your HUB. It can be operating under 2000m. For the following equipment: HUB Is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
