Summary of Contents for Sibeam Snap MOD6212
- Page 1 SiBEAM Snap™ OEM Module Installation Guide for MOD6212/13...
-
Page 2: Mod6212/13 Diagram
C tunneling for remote I C connections • Fully automatic device detection and connection • Close proximity operation • Single chip IC, direct connector replacement • Integrated antenna • No software driver required ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... -
Page 3: Mod6212/13 Transceiver Module Dimensions
Module Installation Guide MOD6212/13 Transceiver Module Dimensions Figure 2. MOD6212/13 Transceiver Module Dimension (in mm) ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... -
Page 4: Mod6212/13 Transceiver Module Pinout
GPI pin on the opposite side of the wireless link. Also used as I2C tunnel interupt Analog Bi-Dir USB High Speed/Full Speed/Low Speed Neg I/O ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... -
Page 5: Mod6212/13 Transceiver Module Connector
The connector type is DF40 from Hirose Part number: DF40C-30DP-0.4V (51) Description: Dual row Board to Board Receptacle (Plug), 0.4 pitch, 50 pins A=7.52mm, B=5.6mm, C =1.5mm Figure 3. Module side connector. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... -
Page 6: Mod6212/13 Transceiver Module Functional Description
I2C tunneling is a key feature of the MOD6212/13 Transceiver Module. It simply allows an I2C master on the MOD6212 to communicate with I2C devices connected to the MOD6213. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... -
Page 7: Gpi, Gpo, And Ledo
IDLE). This combination of WAKE_UP pin and GPO/INT works together with the I2C Tunnel function to prevent the need for polling on the I2C tunnel from the master side. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... - Page 8 As soon as the MOD6212/13 module detects each other through proximity detection and establishes the RF link within second, user could start the USB data transfer now. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL...
-
Page 9: Modular Approval For Lattice Mod6212/13 Transmitter
The spacing between unshielded side of module and enclosure shall be 3mm or less and must be free of any conducting material within a defined exclusion region (Figure 7). d) The enclosure shall be constructed from non-conducting material adjacent to that exclusion region. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... - Page 10 MFC-VFBGA package Dimension A <= 3mm Module PCB 10mm 10mm 26mm Inward facing shielded side Region with no metal permitted PLAN ELEVATION 2.5mm 2.5mm 2.5mm Figure 7: Module placement restrictions ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL...
- Page 11 Made In China Lattice Semiconductor Corp. Proposed Module Location 5.0 mm Sibeam Snap Technology Transceiver module:MOD6213 FCC ID: UK2-MOD621X 204-630016 IC : 6705A-MOD621X Made In China Lattice Semiconductor Corp. 26 mm ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL...
-
Page 12: Important Note
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IMPORTANT NOTE: ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... -
Page 13: Label Of The End Product
(2) this device must accept any interference received, including interference that may cause undesired operation. This Module may not be integrated into host devices that are addressed for operation inside airplanes/satellites. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL... - Page 14 Module Installation Guide ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL...
- Page 15 Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de de distance entre la source de rayonnement et votre corps. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL...
- Page 16 6705A-MOD621X". The Host Model Number (HMN) must be indicated at any location on the exterior of the end product or product packaging or product literature which shall be available with the end product or online. ©2017 SiBEAM, Inc., a Lattice Semiconductor company. All rights reserved. CONFIDENTIAL...
