Summary of Contents for AllPondSolutions JY Series
- Page 1 COLUMN AQUARIUM INSTRUCTION MANUAL JY & JYS TANK RANGE...
- Page 3 To ensure safe enjoyment and understanding of your aquarium please read and follow all the safety instructions and important notices below before using at setting up your aquarium. Failure to do so may result in injury or damage to the unit.
- Page 4 · A “drip loop” should be arranged to the socket. The “drip loop” is that part of the cord below the level of the socket (or the connector if an extension cord is used), to avoid water travelling along the cord and coming into contact with the wall socket.
- Page 5 Do not attempt to repair any product component yourself: if any damage · has occurred, replace the damaged component with original spare parts, or contact the manufacturer for further advice. This equipment can be used by children aged from 8 years and above and ·...
- Page 6 ADDING WATER TO YOUR TANK Fill your aquarium with water up to the level indicated on the label located on the inside of the aquarium's top frame. IMPORTANT! DO NOT OVER FILL YOUR AQUARIUM. Overfilling the tank can cause water to pass under the top frame which then runs down the inside of the aquarium.
- Page 7 Never use toxic or inappropriate substances to clean your aquarium, such · as household or garden detergents. IMPORTANT! It is ESSENTIAL to place the aquarium on the corresponding cabinet which was designed with the correct dimensions and structure to bear the weight of the aquarium full of water.
-
Page 8: Parts Diagram
PARTS DIAGRAM Bottom filter tray & foam LED light unit Bio balls Venturi pipe Water filter pump Water outlet for filter Air pump Flexi pipe for pump to filter Glass cover Filter box lid Top filter tray & spray bar Heater T piece for air pump Clear hard tube... -
Page 9: Installation
INSTALLATION Before adding any equipment to your tank, first position the tank in your desired location and fill with water (see Adding Water to your Tank). Next, connect the two ends of the T piece (7) to the two air pump outlets (4) and then connect to the clear pipe that runs along the back of the tank. - Page 10 Connect the water outlet (12) to the hole in the underside of the bottom filter tray (1). This allows the filtered water to be returned into the tank. Add the black bio balls (2) into the bottom filter tray on top of the filter foam. Lay the clear spray bar (6) across the top of the top filter tray (6) between the two grooves at either end.
-
Page 11: Maintenance Advice
SET UP ADVICE CAUTION: Disconnect the mains electricity supply before placing your hands in your aquarium water or carrying out any installation or maintenance of any kind. Once you have installed any outlet/inlet pipework, do not move the tank · and/or cabinet as this can cause damage to the pipework and the acrylic tank. - Page 12 For further maintenance guidance, please see the table and additional information below: 1 MONTH 3 MONTHS 6 MONTHS ANNUALLY Impeller Clean & Inspect Replace Ceramic Shaft Clean & Inspect Replace All Pipework Clean & Inspect Hosing Clean & Inspect Heater Clean &...
- Page 13 When topping up tank water it is essential to add the appropriate amount of · dechlorinator or water conditioner; not just adding water from a tap. Do not leave lights on for more than 6-8 hours as over-usage may result in ·...
- Page 14 rubbers stay in the holes that they fit into and will not be obviously evident when first removing the impeller and shaft). Note: Handle the ceramic shaft with care as this can break very easily during the cleaning process. Adding Filter Media Filter media is designed for use in filter bays and will help clean circulating water and maintain essential bacteria.
-
Page 15: Replacement Parts
For a full listing of replacement parts please visit www.allpondsolutions.co.uk/spare-parts WARRANTY Your aquarium is guaranteed against defects in material or workmanship under normal aquarium usage and comes with 12 months warranty for all electrical parts and 6 months warranty for the glass / acrylic tank. - Page 16 these. The warranty also does not cover wear and tear or any parts which have not been adequately or correctly maintained. This guarantee is valid providing the aquarium has been situated in a suitable location. This location must be flat and level, and has been installed in consistence with the installation instructions and this document.
