- Page 1 OperatOr’s Manual www.lakegroomer.com P/N 4026288...
- Page 2 This manual may not be reproduced, photocopied, copied, duplicated or translated without prior written consent from Lake Groomer. Using this product in methods not intented by Lake Groomer are strictly prohibited without prior written permission from Lake Groomer. CONSULT YOUR STATE AND LOCAL AUTHORITIES FOR WEED REMOVAL REGULATIONS.
-
Page 3: Table Of Contents
Safety Decals ......................11 SECTION 5 - ASSEMBLY & SETUP Box Contents ......................12 Before Operating ....................12 Becoming Familiar with Lake Groomer’s Movement and Controls ....13 Sensor Clearance ....................13 Choosing the Best Dock Mount Position .............. 14 Preparing the Rollers ....................15 Installing Lake Groomer ..................15... -
Page 4: Section 1 - Introduction
Initially, you will want to run Lake Groomer continuously, any time the lake front is not in use. After the first three to seven days, once existing weed growth has been removed, it will only need to be cycled 1-5 hours per week. - Page 5 We recommend that you talk with them before installing Lake Groomer to explain how it works and to reassure them that it will not cause any harm to water quality or lake life.
-
Page 6: Terms
Consists of auger tube with lake bed auger at one end and tube drive at the other. Used to anchor Lake Groomer into the ground. Use a 1/2 inch drive ratchet or speed wrench to turn the auger tube assembly into the ground. -
Page 7: Product Registration
In the event of a failure, return the product (at your cost) along with proof of purchase, to the selling Lake Groomer dealer. Eastside Machine Company will, at its option, repair or replace any parts found to be defective in material or workmanship. -
Page 8: Section 3 - Warranty
Eastside, at its discretion, may periodically offer limited, written enhancement to this warranty. Eastside Machine Company reserves the right to change the design and/or specifications of the Lake Groomer at any time without obligation to previous purchasers. -
Page 9: Section 4 - Safety Information
• Do not allow swimmers or pets to stand on, dive from or swim near the Lake Groomer. • When Lake Groomer is not in use, park the rollers near the dock or lifts or in another position where it is not likely to come into contact with people. - Page 10 Lake Groomer as they may become entangled with the Lake Groomer unit. • Never run Lake Groomer without the cover in place. To prevent damage to the electrical components, do not leave the cover off. • Always disconnect the power cord before servicing Lake Groomer or entering the water.
-
Page 11: Safety Decals
SAFETY DEcALS Read and understand the safety decals. The information on the decals will inform you of hazards to avoid and keep you safe around the Lake Groomer. Replace damaged or illegible decals and place them in the same location. -
Page 12: Box Contents
ASSEMBLy & SETUP BOX cONTENTS The Lake Groomer comes partially assembled in three separate boxes. ITEM # ITEM BOX 1 700101 Drive Unit Assembly 700110 Lake Groomer Operator’s Manual 702012 Dock Bracket 702013 Dock Connection Bracket 702015 2” Square U-Bolt 5/16-18 x 4.00 702016 2"... -
Page 13: Becoming Familiar With Lake Groomer's Movement And Controls
7. Disconnect the power cord before moving on to the next steps. SENSOR cLEARANcE In order for your Lake Groomer to work properly and to avoid damage to the drive unit, sensor clearance must be set at .03”-.04” , which is about the thickness of a credit card. -
Page 14: Choosing The Best Dock Mount Position
This TOGGLE SWITCH signals the Lake Groomer to run. Toggling the switch off and on again will cause the Lake Groomer to change direction. cHOOSING THE BEST DOcK MOUNT pOSITION... -
Page 15: Preparing The Rollers
1. With the assistance of another person, bring your supplies, including the drive head assembly, partially-assembled rollers and any needed tools or equipment to the area where you plan to install Lake Groomer. We recommend using a box or other container to hold any parts, hardware or tools needed to ensure they don’t slip through your dock or get lost in sand. - Page 16 4. Attach the rollers to the drive unit using the coupler tubes (Figure 4). • Position the Lake Groomer next to the dock pole where you secured the dock bracket, making sure the 2-inch square tube of the Lake Groomer with the dock connection bracket will be able to attach to the dock bracket when positioned in the water.
- Page 17 1/2” X 3 3/4” BOLT 1/2” CENTERLOCK NUT 5. The Lake Groomer is now ready to be placed in the water! You will have a short time to position the Lake Groomer near the dock bracket while the tube assembles fill with water and sink.
- Page 18 8. Use a 1/2” ratchet or speed wrench to drive the auger tube into the ground. It is recommended the auger tube be at least 12 inches into the ground. 9. The Lake Groomer is now ready to have the power cord attached. We recommend using zip ties to attach the cord to your dock. Approximately three seconds after the unit is plugged in, you should see the lights on the sensors illuminate.
-
Page 19: Setting Travel Limits
Directional pucks may need to be reset after your area is cleared or after a weather event that causes abnormal wave action. NOTE: After clearing the designated area, the Lake Groomer will only need to run periodically (1-5 hours per week) to maintain a clean lake bottom. -
Page 20: Section 6 - Extra Features
Imagine what happens to a vehicle when it gets stuck in the mud: Lake Groomer’s rollers are like the wheels of a vehicle. If the rollers are spinning but not able to move, they will get stuck in the muck. The deeper the muck or the longer the rollers spin, the harder they will be to dislodge, and the unit may become damaged. -
Page 21: Increasing/Decreasing The Load Percentage
This will cause the rollers to reverse, and therefore won’t cover your entire intended area. The obstruction needs to be removed, the arc of travel needs to be adjusted or the Lake Groomer needs to be repositioned so the obstruction is not in its path. -
Page 22: Section 7 - Maintenance & Storage
Lake Groomer outdoors where it may be subjected to repeated freeze and thaw. • Store any hardware you have removed in a baggie with your Lake Groomer so it is not misplaced. NOTE: To prevent the spread of aquatic invasive species, it is important to consult state and local regulations regarding transporting and installing Lake Groomer between bodies of water. -
Page 23: Section 8 - Parts
PARTS ROLLERS (TUBE WITH FINS ASSEMBLY) ITEM # DESCRIPTION 703003 Roller Tube 708001 Extrusion, T-Bar Formed 709002 Weldment, Tube Drive 911227 1/4” x 1” Self Drilling Screw 913457 Screw, 5/16” x 3/4” Thread Cutting ZP www.lakegroomer.com... -
Page 24: Lower Drive Assembly
PARTS LOWER DRIVE ASSEMBLY... - Page 25 PARTS DESCRIPTION 703000 Position Base Collar 703001 Position Collar 705000 Base Foot Pad 705001 Base Auger Bracket 705009 Communication Tube Support Plate 707000 Main Frame Upright 707001 Auger Tube 707002 Lower Brace 707003 Gearbox Mount Plate 707004 Gearbox Thrust Washer 707005 Gearbox Bushing 707006...
-
Page 26: Upper Drive Assembly
PARTS UPPER DRIVE ASSEMBLY LAKE GROOMER ELECTRICAL SCHEMATIC... -
Page 27: Detaching The Drive Head
PARTS UPPER DRIVE ASSEMBLY ITEM # DESCRIPTION 93007 Motor, 1/6 HP 3 PH 230V 705008 Motor Mount Base 705010 Sensor Bracket 709004 5/8 Hex 3/4 RND Weldment 713000 Cover w/ Weatherstrip Assembly 910211 #10-24 Nylock Nut 911226 1/4-28 x 5/8 SS HHCS 912260 1/4-20 x 1/2 Setscrew 912262... -
Page 28: Dockless Anchor Kit
911407 SCREW, 3/8 X 2-1/2 ZINC PLATED GRADE 5 CAP 913401 BOLT, 3/8 X 1-1/4 CARRIAGE ZINC PLATED GRADE 5 919020 STEEL TIE-DOWN STAKE 4022470 BOX. ACCESSORY OPTIONS DOCKLESS ANCHOR KIT - 700109 DESCRIPTION 702009 Bracket, Tripod 702010 Bracket, Tube 702011 Bracket, Tube Anchor 707013... -
Page 29: Section 9 - Options
OPTIONS MUD KIT - 700107 ITEM DESCRIPTION 707008 MAIN FRAME EXTENSION DESCRIPTION 707009 COMM. TUBE EXTENSION 709001 Weldment, Drive Coupler 707011 UNION, MAINFRAME EXTENSION 709009 Welment, Mud Attachment 707012 COMM. TUBE UNION 709008 WELDMENT, EXTENSION HEX SHAFT 910609 1/2” Centerlock Hex Nut 910402 NUT, 3/8 NYLOCK ZINC PLATED 911300... -
Page 30: Roller Connect Plate Kit
OPTIONS ROLLER CONNECT PLATE KIT ITEM # DESCRIPTION 702017 Plate, Connect 703006 Spacer, WR Plate 910402 3/8” Nylock Nut 911300 5/16” x 3/4” Cap Screw 911403 3/8” x 1-1/2” Cap Screw... -
Page 31: Section 10 - "Power Share" Program
Invest in Lake Groomer with your neighbors or cover a larger area of your own lake shore by installing one roller assembly at each location and sharing the easily detachable power unit between sites. - Page 32 Lake Groomer 474 45th Street South • Fargo, ND 58103 info@lakegroomer.com 701-234-0476 www.lakegroomer.com...
