Summary of Contents for SGI-DNA BIOXP 3200
- Page 1 BioXp ™ 3200 System: User's Guide REV. 5.0 09.27.18 Part number 40010...
- Page 2 SGI-DNA Limited Warranty; and ii) failure to disclaim implied warranties and limit remedies and liabilities, by and on behalf of SGI-DNA.
- Page 3 IMPORTANT- This agreement (the “Agreement”) is a legal agreement between you and SGI-DNA. By installing or otherwise using the BioXp™ 3200 System (referred in this agreement as the “Product”), you agree to be bound by the terms of this Agreement. If...
-
Page 4: Table Of Contents
Table of Contents Product Ordering Information Safety Information Manual Symbols Precautions Marking Symbols on the Equipment Safety Warnings Equipment Specifications System Components Technical Specifications Installation Guide System Location Unpacking, Set up, and Power Up Getting to Know the System Ethernet Set Up Load the Reagent and Recovery Plate Thermal Covers Starting and Configuring the BioXp™... -
Page 5: Product Ordering Information
1 year, renewable annually Safety Information Manual Symbols This manual describes the use and maintenance of the SGI-DNA BioXp™ 3200 Instrument. Read this manual completely before putting the instrument into service. The following icons are used in this manual: Electrical Safety Warning: Failure to follow these instructions can cause harm to operators or subjects. -
Page 6: Safety Warnings
Use this product only as specified. If the instrument is used in a manner not specified by SGI-DNA, the protection provided by the instrument may be impaired, resulting in personal injury or damage to the instrument. Ground Circuit Protection Check the mains electricity supply plug, voltage, and frequency to confirm that the supply corresponds to the values shown on the instrument label. - Page 7 Flammable Liquids: Solution Handling Warning Keep flammable liquids in covered containers when not in use. Provide means to promptly and safely dispose of any flammable liquid leaks or spills. Do not transfer liquids using air pressure. Read applicable MSDSs. Store flammable liquids in cool, well-ventilated areas away from corrosives, oxidizers, and ignition sources.
-
Page 8: Equipment Specifications
66 cm × 53 cm × 74 cm Installation Guide The following section is included for reference purposes only. As standard practice, SGI-DNA will install the BioXp™ System. CAUTION: Read the entire Installation Guide before unpacking the BioXp™ System. Be sure to read and adhere to the "Safety Warnings"... - Page 9 Setup Precautions Place the instrument on a clean, dry, flat surface capable of holding the weight of the system. Allow 10 cm of clearance on both sides of the instrument for proper ventilation. Make certain that the power cord connection point is free and clear of obstructions so that it is easily accessible.
-
Page 10: Unpacking, Set Up, And Power Up
Unpacking, Set up, and Power Up WARNING! Using the BioXp™ System in a manner not specified by SGI-DNA may result in damage to the equipment and/or personal injury. Remove the crate from the BioXp™ System by positioning two people across from each other. Carefully... -
Page 11: Getting To Know The System
Getting to Know the System Hardware Overview Figure 1. Front and side view of the BioXp™ 3200 Figure 2. The BioXp™ 3200 System Deck. System. Figure 3. Labeled Deck Map. Instrument Ports Location Port/Inlet Used to Do not use Note: The USB port is for instrument diagnostics and is for authorized service personnel use only. -
Page 12: Ethernet Set Up
Ethernet Set Up The BioXp™ System requires an internet connection. Prior to connecting the instrument to the internet, be sure to test the connection with the executable file provided with the BioXp™ System pre-installation instructions: "Check User Instructions" (BX 3200-21). After testing and confirming the connection as directed, connect the provided RJ45 Ethernet Cable to the Ethernet port located on the rear of the unit to an available Ethernet wall jack located in your lab. -
Page 13: Starting And Configuring The Bioxp™ System
Starting and Configuring the BioXp™ System Start the BioXp™ System Turn the instrument on using the power switch located on the side of the instrument. If prompted, update the software. The BioXp™ System will initiate a self-check process to verify the correct functionality of motion control and other internal systems of the instrument. -
Page 14: Operational Features Of The Bioxp™ System
Operational Features of the BioXp™ System Delay Start The Delay Start function is a useful tool enabling you to schedule job runs at your convenience. Immediately after a Delay Start is scheduled (before the delay time period elapses), the instrument initiates reagent mixing from the Reagent Strips and the Reagent Plate. -
Page 15: Tracking Progress During A Run
Tracking Progress During a Run Time to Completion During a run, the instrument will display the projected time to completion for the job (in hours : minutes : seconds) and the estimated Time of Completion, as shown in the following illustrations: Step 1 Example Step 2 Example... -
Page 16: Cancel A Run
Cancel a Run If you need to cancel a job during a run, slide your finger Slide to cancel to the right across the bar on the bottom of the Display Screen During a Run. IMPORTANT! You will not be able to reuse reagents if you cancel a job after the run has initiated and the Reagent Plate Seal has been broken. -
Page 17: Instrument Troubleshooting
If you observe a red-background error screen during operation, follow the screen instructions. If directed or if the problem persists, make a note of the screen and Call SGI-DNA Customer Service at 1-855-474-4362. Additional information is included in the following table:... -
Page 18: Cleaning And Maintenance
The system will perform a self-check upon power up the first time each day. A log of the self check is stored on the system and may be used by SGI-DNA Service Technicians should any issue arise. Preventative Maintenance The BioXp™... -
Page 19: Recommended Separation Distances
Equipment and Systems that are NOT Life-supporting The BioXp™ System is intended for use in the electromagnetic environment specified below. The customer or user of the BioXp™ System should ensure that it is used in such an environment. The BioXp™ System is intended for use in the electromagnetic environment in which radiated disturbances are controlled. -
Page 20: Fcc Compliance Statement
IEC 61000-4-8 or laboratory environment. NOTE: U is the AC mains voltage prior to application of the test level. Technical Services: For technical assistance, please contact technical services at techservices@sgidna.com. © 2018 SGI-DNA. All rights reserved.
