「WARNING」は、高さ2.4mm
以上の文字で記載
IMPORTANT
This manual contains safety information. Read manual completely before first using this product and save this
manual for future use.
IMPORTANTE
Este manual contiene información de seguridad. Lea completamente este manual antes de utilizar por primera vez
este producto, y guárdelo para poder consultarlo en el futuro.
Cordless Impact Driver
Destornillador de impacto inalámbrico
Operating Instructions
Manual de instrucciones
Model No: HTP-CID
Advertisement
Table of Contents
Summary of Contents for Huskie Tools HTP-CID
-
Page 1: Operating Instructions
Cordless Impact Driver Destornillador de impacto inalámbrico Operating Instructions Manual de instrucciones Model No: HTP-CID 「WARNING」は、高さ2.4mm 以上の文字で記載 IMPORTANT This manual contains safety information. Read manual completely before first using this product and save this manual for future use. IMPORTANTE Este manual contiene información de seguridad. Lea completamente este manual antes de utilizar por primera vez... - Page 2 Index/ Indice English: Page Español: Página FUNCTIONAL DESCRIPTION DESCRIPCIÓN FUNCIONAL (I) (H)
- Page 3 6.35 mm hex quick connect chuck Nose protector Mandril hexagonal de conexión rápida Protector del morro de 6,35 mm Forward/Reverse lever Belt hook Palanca de avance/inversión Gancho del cinturón Battery pack Battery pack release button Batería Botón de liberación de batería Control panel Battery level button Panel de controle...
- Page 4 [Fig.1] [Fig.5] 6.35 mm (1/4″) 9.5 mm (3/8″) Pack cover Cubierta de batería Terminals Bornes Terminales [Fig.2] Label (red or yellow) Alignment marks Etiqueta (roja o amarilla) Marcas de alineación [Fig.6] Battery pack release button Button Botón de liberación de batería Botón Alignment marks Attaching...
-
Page 5: Limited Warranty
This tool, as a complete unit with a battery 3) Keep children and bystanders away pack, satisfies appropriate IP Degrees of while operating a power tool. Protection based on the IEC regulations. Distractions can cause you to lose control. Definition of IP code Electrical Safety IP5X: Ingress of dust is not totally prevent- ed, but dust shall not penetrate in a quan-... -
Page 6: Personal Safety
Power Tool Use and Care Personal Safety 1) Stay alert, watch what you are 1) Do not force the power tool. Use doing and use common sense the correct power tool for your when operating a power tool. Do application. not use a power tool while you are The correct power tool will do the job tired or under the influence of... -
Page 7: Specific Safety Rules
Battery Tool Use and Care 3) Hold power tools by insulated gripping surfaces when performing an opera- 1) Ensure the switch is in the off tion where the cutting tool may position before inserting battery contact hidden wiring. pack. Contact with a “live” wire will make Inserting battery pack into power tools exposed metal parts of the tool “live”... -
Page 8: Important Safety Instructions
3) CAUTION—To reduce the risk of attempting any maintenance or clean- injury, charge only Huskie Tools ing. Battery Pack as shown in last page. 12) The charger and battery pack are Other types of batteries may burst specifically designed to work together. - Page 9 15) Do not store the tool and battery pack WARNING in locations where the temperature • Do not use other than the Huskie Tools may reach or exceed 50°C (122°F) battery packs that are designed for use (such as a metal tool shed, or a car in with this rechargeable tool.
-
Page 10: Operation
IV. ASSEMBLY [Main Body] CAUTION Attaching or Removing Bit • When storing or carrying the tool, set NOTE: the Forward/Reverse lever to the When attaching or removing a bit, center position (switch lock). disconnect battery pack from tool or place the switch in the center position NOTE: (switch lock). - Page 11 Changing the Belt Hook Location Soft • Jobs requiring limited Side [Fig.4] torque with eliminating the possibility of break- The belt hook can be attached to either ing screw, chipping side of the unit. screw head, or break- 1. Removing the hook ing bit.
- Page 12 LED Light Overheat warning Press the light button and set illumination condition. Illuminated Illuminates by pressing button. Illuminated: Flashing: The light turns off when the tool (normal Overheat Overheat has not been used for more operation) (motor) (battery) than 5 minutes or just after attaching the battery pack.
- Page 13 [Battery Pack] NOTE: The indicator will not show the battery For Appropriate Use of level even the button is pressed in the following cases. Battery Pack [Fig.5] • The main unit is powered off. • The rechargeable batteries have a •...
- Page 14 2) The ambient temperature range is NOTE: between 0°C (32°F) and 40°C Not all battery packs display the (104°F). alignment mark (Q) (on page 2). If the battery pack is used when the Slide forward in the direction of the battery temperature is below 0°C arrow.
-
Page 15: Lamp Indications
LAMP INDICATIONS Charging is completed. (Full charge.) Battery is approximately 80% charged. Now charging. Charger is plugged into the AC outlet. Ready to charge. Charging Status Lamp. (Green) (Orange) Left: green Right: orange will be displayed. Battery pack is cool. The battery pack is being charged slowly to reduce the load on the battery. -
Page 16: Specifications
VIII. APPENDIX MAXIMUM RECOMMENDED CAPACITIES Model No. HTP-CID Wood screw Φ 3.5 mm – Φ 9.5 mm (1/8″ – 3/8″) Screw driving Self-drilling screw Φ 3.5 mm – Φ 6 mm (1/8″ – 1/4″) Standard bolt : M6 – M16 (1/4″ – 5/8″) Bolt fastening High tensile bolt : M6 –... -
Page 17: Battery Pack
BATTERY PACK Model No. BP-185 Storage battery Li-ion battery 18 V DC Battery voltage (3.6 V × 10 cells) NOTE : This chart may include models that are not available in your area. Please refer to the latest general catalogue. BATTERY CHARGER Model No. - Page 18 195 Internationale Blvd Glendale Heights, IL 60139 Phone 800-860-6170 Fax 800-345-3767 www.huskietools.com...
