Summary of Contents for Godwing Electronics CD-1560B
- Page 1 ＣＤ ＣＤ－ － １５６０Ｂ ＴＦＴ ＬＣＤ Ｃｏｌｏｒ Ｍｏｎｉｔｏｒ １５６０Ｂ ＴＦＴ ＬＣＤ Ｃｏｌｏｒ Ｍｏｎｉｔｏｒ Ｕｓｅｒ＇ｓ ｍａｎｕａｌ Ｕｓｅｒ＇ｓ ｍａｎｕａｌ...
-
Page 2: Table Of Contents
CONTENTS Introduction……………………………………………………….2 Precautions………………………………………………….….…2 Cleaning the TFT LCD Color Monitor………………………..….3 Package contents………………………………………………….3 Installation …………………………………………………...…3 a. Installation location(Illustrate vertical scope)……………….4 b. Connect the signal cable……………………………………..4 c. Connect the power cord………………………………………4 Operation ………………………………………………………..4 a. Angle of pitch and horizontal position adjustment………..…4 b. Power Switch and power-on………………………………… 5 c. -
Page 3: Introduction
c. Introduction The advantages of LCD monitor are that it has not harmful X radiation caused by high energy electron bombing the screen. It also has not air pollution caused by screen high voltage static electricity molecule adsorbing. And because of its soft and steady image quality, your eyes will never feel dry and sore. -
Page 4: Cleaning The Tft Lcd Color Monitor
on the LCD. If smoke, abnormal noise, or strange odor is present, immediately switch the LCD off and call your dealer. It is dangerous to continue using the LCD. Never remove the rear cover, because the display unit contains high-voltage parts and you may suffer electric shock if you touch these parts. -
Page 5: Installation Location(Illustrate Vertical Scope)
Make sure that your monitor will be set up on a stable surface. The Power socket will be near the monitor. Choose a well-ventilated space to position your monitor. m. Avoid exposing the LCD to direct sunlight. Adjust the environmental light for the best viewing condition. b. -
Page 6: Power Switch And Power-On
b. Power Switch and power-on Power Switch Power switch locates on the back of monitor Press I , turn monitor on press O, turn monitor off Once the power switch turns on, you needn’t turn it off, you need only control and switch on the panel. When PC powers off or enters power-saving state, the power of monitor will automatically change to power-saving state. -
Page 7: Osd Function Control Keys
OSD(On Screen Display) Keys Your TFT-LCD Color Monitor is controlled by five easy to use buttons----Screen ON/OFF , Menu, +, -, Select(Fig4-1). OSD Controls and Adjustments OSD menu will be appears by clicking the menu key. You can use the four OSD keys for controls and adjustments of optional value.(e.g. -
Page 8: Osd Chart Illustration
OSD Main Menu AUTO ADJUSTMENT By select this item, the system will automatically adjust the clock, phase, H-position and V-position values. CLOCK By selecting this item, you can adjust the main clock value. PHASE By selecting this item, you can adjust the phase of clo... - Page 9 H-POSITION By selecting this item, you can adjust the horizontal position of screen. V-POSITION By selecting this item, you can adjust the vertical position of screen. OSD DISPLAY TIME By selecting this item, you can adjust the display time of OSD. CONTRAST By selecting this item, you can adjust the contrast.
- Page 10 LANGUEGE By selecting this item, you can select the language of OSD. COLOR CONTROL By selecting this item, you can adjust the color temperature.
- Page 11 RESET By selecting this item, all mode settings are stored in the EEPROM by factory will be restored. BRIGHTNESS By selecting this item, you can adjust the brightness. OSD WINDOW LOCATION By selecting this item, you can adjust the location of OSD window.
-
Page 12: Troubleshooting
Troubleshooting PROBLEM SOLUTION The power switch is on, but The Check and make sure that the LED light doesn't work. power cord and signal cable are securely connected, then press key on the front panel. There is a glaring line at the edge Enter MENU, select... -
Page 13: Technical Data
8 Technical data Model Name CD-1560 Display Type Display Size 15" Resolution 1024X768 Pixel Pitch 0.297(H)X0.297(V) Display Area 304.128(H)X228.096(V) Response Time 20ms Number of Colors 16,194,277 Contrast 300 : 1 Brightness 250 cd/m Viewing angles Horizontal: -65 ~ +65 Vertical: -40 ~ +50 Input Signal Analog RGB: 0.7Vpp Input Connector... - Page 14 FCC INFORMATION This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
