- Page 1 Bio-Filter Stormwater Biofiltration System Inspection and Maintenance Manual March 2017 AquaShield, Inc. 2733 Kanasita Drive, Suite 111 Chattanooga, TN 37343 Phone: (423) 870-8888 Fax: (423) 826-2112 Email: info@aquashieldinc.com © AquaShield , Inc. 2017...
- Page 2 AquaShield, Inc. Bio-Filter Table of Contents AquaShield Bio-Filter Overview Bio-Filter Operation Bio-Filter Inspection & Maintenance Appendix 2733 Kanasita Drive, Suite 111, Chattanooga, Tennessee 37343 Phone (423) 870-8888 Fax (423) 870-2112 www.AquaShieldInc.com...
-
Page 3: Tm Tm
Each system is custom engineered for site-specific needs using proven lightweight and durable Polymer Coated Steel (PCS). The system operates under gravitational and hydrodynamic forces with no moving parts which simplifies the treatment process. The standard Bio-Filter system utilizes... - Page 4 4 x 4 feet to 8 x 8 feet (16 to 64 square feet). An optional cylindrically shaped Bio-Filter model uses an external bypass structure(s) in lieu of the internal bypass, having similar surface areas as the standard models.
- Page 5 3. Biofiltration Chamber 4. Outlet Chamber 5. Internal Bypass These system components are identified in Figure 1. The five steps of Bio-Filter treatment are described in the sections below. Step 1: Inlet and Trash Shelf Operation begins when water enters the Bio-Filter™, such as a curb inlet, and flows onto the screened Trash Shelf.
- Page 6 Figure 1. AquaShield Bio-Filter System and its five design elements Step 2: Pretreatment The water quality treatment flow enters the Pretreatment Chamber where coarse sediment and oil are captured and retained by principles associated with hydrodynamic vortex separation, such as that incorporated into the design of the ®...
- Page 7 Bio-Filter Biomedia The natural proprietary engineered biomedia used in the Bio-Filter system is capable of removing waterborne pollutants such as fine silts and clays, oil and heavy metals bound to particulate matter (copper, lead, zinc) and phosphorus.
-
Page 8: Bio-Filter
(3) the nature of the area being drained. In order to ensure that our systems are being properly maintained, AquaShield™ offers a maintenance solution to all of our customers. We can arrange to have a maintenance event performed. - Page 9 15 inch diameter metal access cover located closest to the Inlet. It is important to consistently keep both the Inlet and Trash Shelf significantly free of accumulated materials to ensure proper operation of the Bio-Filter unit. Materials can be removed by the use of a vacuum truck while performing maintenance of the other Bio-Filter components.
- Page 10 Replacement mulch and biomedia is available from AquaShield The Underdrain Pipe is accessible through the metal access port for the Trash Shelf.
-
Page 11: Appendix
APPENDIX Inspection and Maintenance Data Sheets... - Page 12 5. Replace removed mulch and biomedia as needed being careful not to significantly disturb tree 6. Replace tree grate prior to departing site 7. Contact AquaShield™ Maintenance Department for replacement biomedia, mulch tree grate or metal covers at 888-344-9044. Inspection - Underdrain Pipe and Outlet Chamber 1.
- Page 13 Maintenance Schedule During Construction Inspect the Bio-Filter™ every three months and clean the system as needed. The Bio-Filter™ should be inspected and cleaned at the end of construction regardless of whether it has reached its sediment or oil storage capacity.
- Page 14 Time Frame NOTES: 1. Attach site plan showing Bio-Filter™ location. 2. Attach detail drawing showing Bio-Filter™ dimensions and model number. 3. If an External Bypass structure is used, attach details showing basic design and elevations. Bio-Filter I and M Manual...
- Page 15 As Needed Clean System* *If the Bio-Filter™ did not reach full sediment or floatable pollutant capacity in the First Year Post-Construction, the system can be inspected and cleaned once annually. If the Bio-Filter™ reached full sediment or floatable pollutant capacity in less than 12 months in the First Year Post-Construction, the system should be inspected once every six months (more frequently if past history warrants) and cleaned as needed.
